Kolver EDU 2AE/TOP Manual page 18

• CN4 CONNECTOR:
All of the following pins are output.
PIN NAME
1 OUTPUT 1
2 OUTPUT 2
3 OUTPUT 3
4 OUTPUT 4
5 OUTPUT 5
6 OUTPUT 6
7 OUTPUT 7
8 OUTPUT 8
9 COM0VDC
Manual EDU 2AE/TOP e EDU 2AE/TOP/TA Rev.0
It indicates you're using program 1
It indicates you're using program 2
It indicates you're using program 3
It indicates you're using program 4
It indicates you're using program 5
It indicates you're using program 6
It indicates you're using program 7
It indicates you're using program 8
Common to every input. Signals have to be enabled making contact between
the desired signal and this pin ( common 0VDC) .
FUNCTION
