• CN5 CONNECTOR (25 pin connector - female):
PIN NAME
1 +5V
DC
2 +24V
PLC
3 OUTPUT 1
4 OUTPUT 2
5 OUTPUT 3
6 OUTPUT 4
7 OUTPUT 5
8 OUTPUT 6
9 OUTPUT 7
10 OUTPUT 8
11 STOP MOTOR
12
13 COM 0V
DC
14 COM +15V
CC
15 INPUT 1
16 INPUT 2
17 INPUT 3
18 INPUT 4
19 INPUT 5
20 INPUT 6
21 INPUT 7
22 INPUT 8
23 RESET EXT
24 ESC EXT
25 OK EXT
• CN6 CONNECTOR (serial connector 9 pin - male) - PRINT FUNCTION
PIN NAME
1 COM +15V
CC
2 RX
3 TX
4
5 COM 0V
DC
6
7
8
9 COM +5V
DC
Manual EDU 2AE/TOP e EDU 2AE/TOP/TA Rev.0
+5V available on this pin, it can't be used to charge external devices
DC
+24V available on this pin, they can't be used to charge external devices.
PLC
It indicates you're using program 1
It indicates you're using program 2
It indicates you're using program 3
It indicates you're using program 4
It indicates you're using program 5
It indicates you're using program 6
It indicates you're using program 7
It indicates you're using program 8
It indicates stop motor is enabled
Not used
Common to every input. Signals have to be enabled making contact between
the desired signal and this pin ( common 0VDC) .
+15V
available on this pin
CC
Switch – selection of program 1
Switch – selection of program 2
Switch – selection of program 3
Switch – selection of program 4
Switch – selection of program 5
Switch – selection of program 6
Switch – selection of program 7
Switch – selection of program 8
If enabled (see point 4: Keyboard commands, in the option menu), it resets
program or sequence according to the preset function (see point 5: Reset , in
the option menu)
If enabled (see point 4: Keyboard commands, in the option menu), ESC key
function to reset remote errors.
If enabled (see point 4: Keyboard commands, in the option menu), remote
OK key function.
+15V available on this pin, it can't be used to charge external devices.
CC
Serial reception
Serial transmission
Common to every input. Signals have to be enabled making contact between
the desired signal and this pin ( common 0VDC) .
+5V available on this pin, it can't be used to charge external devices..
DC
FUNCTION
, not used to charge external devices
FUNCTION
