IVIS Spectrum Hardware Manual
®

6.9 Acquisition Computer

6.10 Accessory Cable

Figure 6.7 IVIS Spectrum, back view
The system includes a Windows
software as well as Microsoft Office software is installed on the computer. The
Living Image software controls the IVIS Spectrum, and displays and analyzes
the image data. A 20-inch monitor and a 10/100 Ethernet network adapter card
are also included. A printer may be attached to the computer.
The IVIS Spectrum is equipped with an electrical connector that enables the
transfer of signals to or from the back panel of the instrument. The back panel
connector is accessible at the rear of the instrument and the stage
(Figure 6.8)
connector is located inside the imaging chamber
guidelines for pin usage.
Table 6.1 Connector pin usage
Pin Number Function
1 to 5 These pins are optimized for transport of ECG (EKG) signals and use
shielded cabling that maximizes the signal-to-noise ratio. An off-the-
shelf ECG monitor may be connected to this connector (for example,
the THM100, Indus Instruments). Pin 1 (ECG ground) in this particular
case, may be left unconnected.
6 to 9 Use these pins to connect a pulse-oxymetry system (for example, the
Nonin OEM III module (internal OEM Oxymetry), Nonin.com)
10 and 11 Use these pins to connect to an Infusion pump that you mount inside
the IVIS Spectrum imaging chamber.
Ventilation openings
Ventilation openings
-based personal computer. The Living Image
®
(Figure 6.9)
®
. shows
Table 6.1
