2. Specifications

Model number of ionizer
Ion generating method
Voltage applying method
Discharge output
Ion balance
Ozone generated amount
Fluid
Air
Operating pressure
purge
Connected tube diameter
Power supply voltage
Current consumption
Input
signal
Output
signal
Effective charge eliminating distance
Ambient temp.
Fluid temp.
Ambient humidity
Material
Vibration resistance
Impact resistance
Weight
Applicable standard/directive
Note 1) This is the value when measured by a probe with 1,000 MΩ and5 pF.
Note 2) This specification is applicable when the distance between the charged object and the
ionizer is 100 mm using the power saving static elimination nozzle, and the air purge
pressure is 0.3 MPa.
Note 3) This is the value from which the background is drawn with a distance of 300 mm from the
front face of the nozzle.
Note 4) Charge elimination is not available without air purge. Also, without air purge, internal
ozone concentration will increase and adversely affect the product and peripheral
equipment.
Note 1)
Note 2)
Note 3)
Note 4)
Discharge stop signal
Reset signal
External switch signal
Discharge signal
Error signal
Maintenance signal
IZN10-□□
(NPN)
Corona discharge type
High frequency AC type
±10 V at max.
0.03 ppm (0.05 ppm for energy saving charge
elimination nozzle）
Air (clean and dry)
0.05 MPa~0.7 MPa
6 and 1/4 inch
24VDC±10%
(When input and output signals are not used)
GND to connection
The voltage to turn on is 0.6V
or less.
Current consumption: 5 mA or
less
Max. load current: 40 mA
Residual voltage: 1 V or less
(with load current of 40 mA)
Max. applied voltage: DC 28
V
20~500 mm
35~65% RH（With no condensation）
Body: ABS, Stainless Nozzle: Stainless
Electrode needle: Tungsten
Durable to 50 Hz with amplitude 1 mm for 2 hours in
each X, Y and Z direction
CE (EMC directive: 89/336/EEC, 92/31/EEC、
93/68/EEC, 2004/108/EC, Low-voltage directive:
73/23/EEC, 93/68/EEC)
- 5 -
IZN10-□□P
(PNP)
2500V
80 mA
+24V to connection
The voltage to turn on is from
+19V to the
power supply voltage.
Current consumption: 5 mA
or less
Max. load current: 40 mA
Residual voltage: 1 V or less
(with load current of 40 mA)
o
0~55 C
10 G
120 g
