Operation The user must end any call in progress by pressing the
Indicator lights The Link Dual Charger is designed to charge one Battery Pack at a
Part Number: 72-0035-51-I.doc
the handset before placing the handset into the charger. The call
will not automatically terminate when the handset is placed in the
charger. The Battery Pack and handset will only fit into the charger
compartments one way. The handset should be inserted into the
front slot, facing forward. The Battery Pack alone should be
inserted into the rear slot with the side that attaches to the handset
facing to the rear. See the cover photo for the correct orientation.
Correct placement has been achieved when the charging light is
activated. Incorrect placement will not activate the charging light.
time. Each charging slot has a red light that indicates its current
mode. The charging lights have the following characteristics: When
both a Battery Pack and a handset are present at the same time, the
first one placed into the charger will begin charging. When it is fully
charged, the second Battery Pack will charge. When the LED
indicator light turns off, the charger is finished charging the Battery
Pack in its slot, indicating that the Battery Pack is ready for use. The
Link Dual Charger will recharge a single NiMH Battery Pack or a
single handset in two hours.
Indication Light Charging Characteristic
Solid On Charging.
Solid Dim Waiting to charge. Battery Pack in other slot is
charging.
Off Done charging, empty slot or unit is not
powered.
Flash Error. Battery Pack not charging. Try again or
replace Battery Pack.
Link Wireless Telephones and Accessories User Guide
key on
END
