- Page 1 REMKO DZ 18 HD Automatic oil heater Operation Technology Spare Parts Edition GB – M04 REMKO - powerful like a bear.
-
Page 3: Table Of Contents
Our guarantee will become void when the unit supplied by us is used and installed for inadequate purposes, or maintained incorrectly, etc., or if it is changed without our prior consent. Subject to alterations! Automatic oil heater REMKO DZ 18 HD Contents Contents Page Page... -
Page 4: Safety Instructions
Safety Instructions Description of Device Please make sure that the relevant local building The unit is fired directly with heating oil EL or diesel. It is and fire protection codes as well as the regulations intended for mobile and fully automatic deployment and of the employer's liability insurance associations operated without an exhaust system. -
Page 5: Provision Of Air Heaters
Provision for Air Heaters For the deployment of the unit, the relevant guidelines Examination must be observed 4.1 The unit must be tested by an expert as to its work Operating personnel safety specific condition in accordance with the re- quired deployment conditions but at least once an- 1.1 The unit must only be operated by persons who nually. -
Page 6: Installation Instructions
Installation Instructions Starting The units are generally to be operated in accordance Prior to starting, the unit is to be checked to make sure with the safety rules, the building code of the land con- that there are no visible defects on the control and cerned and the fire protection code. -
Page 7: Unit Shut Down
Fuel Pump The standard type of the pump runs in a system of Heating without room thermostat 1 pipe. The required fuel is sucked in through the suction The unit runs in continuous operation. line "S". For the first starting and after having emptied the fuel tank, the fuel system is deaerated through the burner 1. -
Page 8: Change The Pump To A 2 Pipe System
Change the Pump to a 2 Maintenance and Service Pipe System The unit is to be maintained regularly whereby some fundamental rules are to be observed to ensure a long If an external fuel tank is used, the pump can be service life and trouble-free operation. -
Page 9: Burner Adjustment
Cleaning the fuel tank Adjustments of the burner head It is necessary to clean the fuel tank: Fine adjustment of air slide plate by means of CO indicator and soot pump. ◊ After each heating period or, depending on the deploy- - value: approx. -
Page 10: Exploded View
Exploded View We reserve the right to make modifications in dimensions and construction in the interests of technical progress. -
Page 11: Spare Part List
Spare Part List Description Ref.-No. transport handle 1108131 inspection cover 1101801 protective socket, small 1102131 ignition cable, kit 1102159 protection hose 1101617 ignition electrode 1108087 photo cell 1108209 fastening plate (photo cell holder) 1300980 photo cell holder 1102126 clamp (thermostat) 1102128 recool thermostat 1101027... -
Page 12: Wiring Diagram
REMKO-heater and has returned it failures occurs though which cannot be eliminated by the to REMKO GmbH & Co. KG in due time after the unit’s operating person, please contact your dealer or contact sale and commissioning. -
Page 13: Troubleshooting
Troubleshooting Trouble: Cause: – unit does not start. 2 – 3 – 4 – 5 – 6 – 7 – motor is running but burner will not be ignited. 1 – 8 – 9 –10 – 11 – 12 – 13 –14 –15 – 16 – 18 –19 – 21 – 22 –... -
Page 14: Maintenance Log
Maintenance Log Model : ........ Model No. : ........9 10 11 12 13 14 15 16 17 18 19 20 Clean unit -surface- Clean unit -interior- Clean fan Clean combustion chamber Clean burner head Adjust ignition electrode Replace nozzle Clean / replace fuel filter Adjust / measuring burner Check safety facility... - Page 16 REMKO GmbH & Co. KG Klima- und Wärmetechnik D-32791 Lage Im Seelenkamp 12 • D-32777 Lage PO Box 1827 • Phone +49 (5232) 606 - 0 +49 (5232) 606260...
