ZyPer4K

Optional Ports: USB

A
Port Name Index
USB A
Important Note
The USB system requires its own IP Address that is different and independent from the IP
Address of the ZyPer4K itself. Customers that are using a DHCP server to generate IP
Addresses must ensure the pool of available IP Addresses accounts for any ZyPer4K USB
devices in the system.
If no DHCP server is available, the USB controller will assign itself a Link-Local address.
However, if there is a DCHP server, but there are not enough addresses available in the pool,
USB connections may fail.
There is no means of setting the USB controller with a Static IP address.

Optional Ports: Display Port

Z4K Dante User Manual
The ZyPer4K Decoder device can be ordered with optional USB
connectivity.
Shown to the left is a unit with the USB option (top) and without the
USB option (bottom) installed. This is a build-time option and is not
retrofittable to the product.
Definition
2 ports of USB 2.0 Type-A connectivity. Either port may be used
and both operate simultaneously.
The ZyPer4K Decoder device can be ordered with an optional
DisplayPort output.
Note: DisplayPort output port does not support any Audio
capabilities.
