ZyPer4K
Port Name
Index
Audio
D
IR-OUT
E
IR-IN
F
RESET
G
Optional Ports: 10Gb Ethernet
Port Name
Index
10G Fiber
A1
10G Copper
A2
Z4K Dante User Manual
Definition
Audio Output Jack. Drives line-level stereo audio on 3.5mm jack.
available on models with Dante Transmitter)
Infrared Commands information passed FROM Encoders to Decoders as
configured by ZMP.
Infrared Commands to be passed TO Encoders as configured by ZMP.
Reset to factory defaults. Using a wire or paper clip, lightly press into this hole
while unit is being powered on. Hold for 10 seconds to reset the unit to factory
defaults.
Definition
10 Gigabit Ethernet Connection. Uses standard 10Gb SFP
devices.
10Gb Ethernet over Cat6a or better cabling. RJ45
Page
A1
A2
4
of
18
(Not
