Physical and Environmental

The following parameters apply to all encoders and decoders unless specifically stated
otherwise.
Type Parameter
A/C Adapter 100-1240VAC 50-60Hz 0.7-0.45A draw on AC Mains
Output Max: 12VDC 2.5A
ZyPer4K unit 12VDC at 1.2A max 12W nominal (Standard Fiber Encoder/Decoder)
power consumption 12VDC at 1.6A max 15W nominal (Standard Copper Encoder/Decoder)
12VDC at 1.2A max 12.5W nominal (Extended input Fiber Encoder)
12VDC at 1.6A max 15.5W nominal (Extended input Copper Encoder)
12VDC at 1.2A max 12.5W nominal (Decoder with Dante Transmitter, Fiber)
12VDC at 1.6A max 15.5W nominal (Decoder with Dante Transmitter, Copper)
USB Option (Adds 660mW power to above versions)
Dimensions 144mm x 175mm** x 43mm* (Decoder or Encoder with no extended option)
(LxWxH) 144mm x 228mm** x 43mm* (Encoder or Decoder with extended option)
maximum envelope 145mm x 164mm x 44mm* (Quiet/Fanless Decoder)
*subtract 6mm from height if rubber feet are removed
** add 48mm to overall width if both mounting ears are installed
Weight 880g (Decoder, Encoder with no extended input option)
850g (Quiet/Fanless Decoder)
1070g (Encoder with extended input option)
1070g (Decoder with Dante Transmitter)
Operating 0° C to +40° C (32° F to 104° F)
Temperature
Non-Operating -20° C to +80° C (-4° F to +176° F)
Temp
Humidity (op/ 20% to 90% (Non-Condensing)
storage)
Coating White, satin anti-microbial powder coat
Black, anti-microbial powder coat (Quiet/Fanless Decoder)
