Decoder Function

The function of the ZyPer4K Decoder device (Decoder) is to accept 10G Ethernet traffic that
represents the information to be decoded and displayed. When the appropriate IP stream is
received the Decoder unit will first strip off the encryption that protects the payload on its transit
across the network. It then reformats the video and audio information for display and plays it
out its HDMI video output. Audio is also played out the appropriate port as included.
Other ports on the Decoder devices are for the carriage of USB, IR, RS232 and audio data as
well as a 1Gbit/second utility port for general purpose connectivity of devices to the 10Gb bulk
data infrastructure.
Common Interfaces on all Decoders:
•
Power Input (12VDC)
•
RS232 Input/Output
•
1Gbit/sec Utility Ethernet Port
•
Analog Audio Output
•
Infrared Input and Output
•
HDMI 2.0 Output
•
Equipotential Grounding Lug
Ethernet Bulk Media Interface:
10Gb Fiber or 10Gb Copper
In total there are 14 different, unique Decoder types that can be ordered.
HDMI Fiber
DisplayPort Fiber
HDMI Fiber with Dante
Transmitter
HDMI Fiber (Quiet/
Fanless)
Z4K Dante User Manual
HDMI Fiber with USB
DisplayPort Fiber with
USB
HDMI Fiber with USB
and Dante Transmitter
HDMI Copper (Quiet/
Fanless)
Page
Optional Interfaces on Decoder Units:
DisplayPort:
(none) or present
USB:
(none) or
2x USB Type-A Interface
Dante Transmitter:
(none) or present
HDMI Copper
DisplayPort Copper
HDMI Copper with
Dante Transmitter
1 of 18
HDMI Copper with USB
DisplayPort Copper with
USB
HDMI Copper with
USB and Dante
Transmitter
