NOTEPAD
5, 8FX, 12FX
APPENDIX 1:
Troubleshooting
signal by referring to the signal path diagrams in Chapter 4.
then the master controls for that bus must be set correctly. For example, even though the signal is always routed to
The internal FX routing has three stages - send, processor, and return. All three must be set correctly for the FX to
be heard.
For an internal FX to be heard, there must be a source contribution from a valid input. Increase the level to the Aux/
FX bus using the Aux/FX control.
to only the clean Master bus.
The signal is return through the corresponding FX Return channel. Troubleshoot that this level is turned up.
APPENDIX 1: NO SOUND?
