GETTING STARTED > PARTS OF THE CONSOLE
The Notepad console features a variety of physical inputs and outputs for getting audio in and out of the
console:
• XLR inputs for balanced audio from a microphone or line level source
•
• RCA inputs for unbalanced consumer audio sources
• USB for computer, smart-phone or tablet digital audio.
• XLR outputs for impedance-balanced signals
•
•
Refer to Section 3.0 for more detail and to section 7.0 for detailed information on USB functionality.
• All mono input channels have both microphone and line-level capability.
•
Refer to Sections 4.2 and 5.1.1 for more detail.
Notepad consoles have two types of stereo inputs.
•
• Stereo RCA - this is the highest numbered stereo channel on the console and offers stereo line level
Refer to Sections 4.2 and 5.1.2 for more detail.
