NOTEPAD
CHANNEL CONTROLS > INPUT CONTROLS
sources and FX Return sources.
5, 8FX, 12FX
HI Z and 100Hz High
Pass Filter
Mic Pre Gain
AUX/FX Send To Effects
Left/Right Pan
Level to Master Bus

5.1: INPUT CONTROLS

The controls are shown in
the order they appear on
the console channel strip -
from top to bottom. This is
not necessarily signal path
order. Please refer to the
relevant signal path dia-
gram (section 4).
Controls common to all
input channel types are
documented in the Mono
Input Channel controls
section (5.1.1). Controls
to Stereo input channels,
the FX Return Channels
are documented in those
sections (5.1.2 and 5.1.3
respectively).
5.1: INPUT CONTROLS
-
