NOTEPAD
CONSOLE ROUTING > AUX MASTER CHANNEL
The Aux Bus sum is sent to the Aux Master output level control. This sum is made up of the aux send
and are not affected by the input channel fader levels.
The Aux Master Channel can also be used to feed monitors, such as headphones or a stage monitor.
Notepad-8FX
The Aux bus is additionally sent to the built-in Lexicon effects processing after the bus master control.
Notepad 12FX
The Aux bus is additionally sent to the built-in Lexicon effects processing before the bus master control.
See section 6 for more details.
5, 8FX, 12FX
4.4: AUX MASTER

4.4: AUX MASTER ROUTING
