CC-Link Gateways
Data transmission modes of the CC-Link Gateways
Bits in Flags
Bit Name
0 0: No Config Error
1 0: AS-i Power OK
2 0. Normal Operation active
3 0: Protected Mode active
EC-Flags
Bit Short Cut
0 Cfg. Err
1 S0
2 Aaasn
3 Aaavail
4 CM
5 !NA
6 APF
7 Offl
8 NPF
9 ... 15
28
Name
Configuration Error
Slave Address 0 detected
Auto Address Assign
Auto Address Available
Configuration Mode active
Normal Operation not active
AS-i Power fail (AS-i voltage below 19V)
Offline
No Peripheral Fault
reserved
Tab. 6-33.
Tab. 6-34.
