CC-Link Gateways
Data transmission modes of the CC-Link Gateways
Buffer memory (write) when using 'IO data only mode'
Address
RWwm0
RWwm1
RWwm2
RWwm3
RWwm4
RWwm5
RWwm6
RWwm7
RWwm8
RWwm9
RWwm10
RWwm11
RWwm12
RWwm13
RWwm14
RWwm15
Bit 15 ... 12 Bit 11 ... 8
AS-i 1: AS-i 1:
Outp. Slv3 Outp. Slv2
AS-i 1: AS-i 1:
Outp. Slv7 Outp. Slv6
AS-i 1: AS-i 1:
Outp. Slv11 Outp. Slv10
AS-i 1: AS-i 1:
Outp. Slv15 Outp. Slv14
AS-i 1: AS-i 1:
Outp. Slv19 Outp. Slv18
AS-i 1: AS-i 1:
Outp. Slv23 Outp. Slv22
AS-i 1: AS-i 1:
Outp. Slv27 Outp. Slv26
AS-i 1: AS-i 1:
Outp. Slv31 Outp. Slv30
AS-i 1: AS-i 1:
Outp. Slv3B Outp. Slv2B
AS-i 1: AS-i 1:
Outp. Slv7B Outp. Slv6B
AS-i 1: AS-i 1:
Outp. Slv11B Outp. Slv10B
AS-i 1: AS-i 1:
Outp. Slv15B Outp. Slv14B
AS-i 1: AS-i 1:
Outp. Slv19B Outp. Slv18B
AS-i 1: AS-i 1:
Outp. Slv23B Outp. Slv22B
AS-i 1: AS-i 1:
Outp. Slv27B Outp. Slv26B
AS-i 1: AS-i 1:
Outp. Slv31B Outp. Slv30B
Bit 7 ... 4 Bit 3 ... 0
AS-i 1:
flags
Outp. Slv1
AS-i 1: AS-i 1:
Outp. Slv5 Outp. Slv4
AS-i 1: AS-i 1:
Outp. Slv9 Outp. Slv8
AS-i 1: AS-i 1:
Outp. Slv13 Outp. Slv12
AS-i 1: AS-i 1:
Outp. Slv17 Outp. Slv16
AS-i 1: AS-i 1:
Outp. Slv21 Outp. Slv20
AS-i 1: AS-i 1:
Outp. Slv25 Outp. Slv24
AS-i 1: AS-i 1:
Outp. Slv29 Outp. Slv28
AS-i 1:
Outp. Slv1B
AS-i 1: AS-i 1:
Outp. Slv5B Outp. Slv4B
AS-i 1: AS-i 1:
Outp. Slv9B Outp. Slv8B
AS-i 1: AS-i 1:
Outp. Slv13B Outp. Slv12B
AS-i 1: AS-i 1:
Outp. Slv17B Outp. Slv16B
AS-i 1: AS-i 1:
Outp. Slv21B Outp. Slv20B
AS-i 1: AS-i 1:
Outp. Slv25B Outp. Slv24B
AS-i 1: AS-i 1:
Outp. Slv29B Outp. Slv28B
Tab. 6-30.
