Center Winder Control
•
Input the tension reference in parameter
parameter 37-21 Tension Set Point.
•
Set parameter parameter 37-57 Tension On/Off to
[1] On, parameter parameter 37-59 Diameter Reset
to [0] Off, and then initiate a start signal.
3 3
Parameter
3-03 Maximum Reference
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time 0.05
5-30 Terminal 27 Digital Output [174] TLD indicator
5-31 Terminal 29 Digital Output [173] End of roll
5-70 Term 32/33 Pulses Per
Revolution
5-71 Term 32/33 Encoder
Direction
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-14 Terminal 53 Low Ref./
Feedb. Value
6-15 Terminal 53 High Ref./
Feedb. Value
6-19 Terminal 53 mode
6-70 Terminal 45 Mode
Parameter 6-72 Terminal 45
Digital Output
6-90 Terminal 42 Mode
6-91 Terminal 42 Analog
Output
6-93 Terminal 42 Output Min
Scale
6-94 Terminal 42 Output Max
Scale
7-00 Speed PID Feedback
Source
7-07 Speed PID Feedback Gear
Ratio
17-10 Signal Type
17-11 Resolution (PPR)
Parameter 37-00 Application
Mode
Parameter 37-20 Winder Mode
Selection
Parameter 37-22 Taper Set
Point
Parameter 37-23 Partial Roll
Diameter Value
Parameter 37-24 Core1
Diameter
Parameter 37-25 Core2
Diameter
Parameter 37-26 Winder Jog
Speed
Parameter 37-27 TLD Low Limit 0
Parameter 37-28 TLD High Limit 90
10
®
VLT AutomationDrive FC 360
Value
50
0.05
Based on the winder encoder.
Based on the winder encoder.
0
10
0
100
[1] Voltage mode
[2] Digital Output
[176] Ready to run
[0] 0–20 mA
[162] Tapered tension set point
0
100
[1] 24V encoder
Based on the application.
Based on the line encoder.
Based on the line encoder.
[0] Drive mode
[0] Wind
0
5.000%
Based on the application.
Based on the application.
1
Danfoss A/S © 11/2014 All rights reserved.
Parameter 37-29 TLD Timer 1
Parameter 37-30 TLDOnDelay 1
Parameter 37-31 Diameter Limit 90
Detector
Parameter 37-32 Initial [0] Set diameter when diameter
Diameter Measurement reset (default)
Parameter 37-33 Diameter [0] No function
Measurement Input
Parameter 37-34 Reading at 0.00
Core
Parameter 37-35 Reading at 0.00
Full Roll
Parameter 37-36 Tension Set [0] Par.3721
Point Input
Parameter 37-37 Taper Set [0] Par.3722
Point Input
Parameter 37-38 Tension [1] Input 53(0–10 V DC or 0–20
Feedback Input mA )
Parameter 37-39 Tension Based on the application.
Feedback Type
Parameter 37-40 Center Winder [1] Parameter 19-61–19-67
Cmd Src control the functions
Parameter 37-41 Diameter 0.02
Change Rate
Parameter 37-42 Tapered 0.2
Tension Change Rate
Parameter 37-43 Diameter 0.5
Calculator Min Speed
Parameter 37-44 Line 0
Acceleration Feed Forward
Parameter 37-45 Line Speed [2] MCB102
Source
Parameter 37-46 Winder Speed 1.000
Match Scale
Parameter 37-47 Tension PID Based on the application.
Profile
Parameter 37-48 Tension PID Based on the application.
Proportional Gain
Parameter 37-49 Tension PID Based on the application.
Derivate Time
Parameter 37-50 Tension PID Based on the application.
Integral Time
Parameter 37-51 Tension PID 0.00%
Out Limit
Parameter 37-52 Tension PID Based on the application.
Der Gain Limit
Parameter 37-53 Tension PID [1] Enable
Anti Windup
Parameter 37-54 Winder Jog 0
Reverse
Parameter 37-55 Winder Jog 0
Forward
Parameter 37-56 New Diameter [0] Core Diameter
Select
