Positioning Control
input would start the homing process, and
switching off the digital input stops the homing
process. In unforced mode, switching on the
digital input would set the current position as the
home position. See Homing Modes for details
about the 3 homing modes.
•
PROFIBUS
-
4 4
-
Send control word PCD 1:0x0084 to the
frequency converter to set current actual position
as the home position.

4.4 Positioning

Settings before Positioning
There are 8 preset target positions. Configure the
attributes of the positions in parameters 37-02 to 37-06.
Set the target window size in 33-47 Target Position Window.
When this parameter is set to 0, the default target window
size, which is 1/256 PPR (pulse per revolution), is used.
Configure the PID factor in 7-33 Process PID Proportional
Gain, 7-34 Process PID Integral Time, and 7-35 Process PID
Differentiation Time based on actual requirements.
Positioning Control Process
Control via digital inputs
Assume that digital input 18 is used to start and stop the
positioning process, while digital inputs 19 and 27 are
used to indicate bit0 and bit1 of an indexed position. The
parameters need to be set as follows:
•
5-10 Terminal 18 Digital Input=[160] Go To Target
Pos.
•
5-11 Terminal 19 Digital Input=[162] Pos. Idx Bit0.
•
5-12 Terminal 27 Digital Input=[163] Pos. ldx Bit1.
Control the positioning process as follows:
•
Use different combinations of index bit values to
select the desired position.
-
-
16
VLT
If 33-00 Homing Mode is set to [1] Forced
Manual Modeor [2] Forced Automated
Mode:
Send control word PCD 1:0x00A0 to the
frequency converter to reset home
status.
Send control word PCD 1:0x0084 to the
frequency converter to start homing.
Send control word PCD 1:0x0080 to the
frequency converter to stop homing.
If 33-00 Homing Mode is set to [0] Home
Not Forced:
Switch both digital input 19 and 27 off
to select position 0.
Switch digital input 19 on and 27 off to
select position 1.
Danfoss A/S © 11/2014 All rights reserved.
®
AutomationDrive FC 360
•
Switch on digital input 18 to start the positioning
process.
•
Switch off digital input 18 to stop the positioning
process.
Control via PROFIBUS
Positioning Setup
•
Set PCD 2 to high 16 bit of the target position in
UU.
•
Set PCD 3 to low 16 bit of the target position in
UU.
•
Set PCD 4 to expected velocity in RPM.
•
Set PCD 5 to expected ramp-up time in ms.
•
Set PCD 6 to expected ramp-down time in ms.
After the set-up is completed, send PCD 2–6 to the
frequency converter.
To start absolute positioning:
1. Send control word PCD 1:0x0084 to the
frequency converter, and wait 100 ms.
2. Send control word PCD 1:0x0481 to the
frequency converter to start the positioning
process.
To start relative positioning:
1. Send control word PCD 1:0x0084 to the
frequency converter, and then wait 100 ms.
2. Send control word PCD 1:0x0881 to the
frequency converter to start the positioning
process.
To stop positioning:
•
Send control word PCD 1:0x0084 to the
frequency converter.

4.5 PROFIBUS Interface

FC 360 frequency converters support Profibus. The Profibus
module is integrated in the control cassette with Profibus.
If Profibus is needed:
•
Order a new frequency converter on which the
control cassette with Profibus is pre-installed.
•
Or order a control cassette with Profibus to
replace the standard control cassette on an
existing frequency converter.
In both cases, ensure that the firmware version is higher
than 1.20.
- Switch digital input 19 off and 27 on to
select position 2.
- Switch both digital input 19 and 27 off
to select position 3.
