Summary of Contents for Cypress CIR-03
- Page 1 CIR-03 Infrared Extender Box and CIR-12 Infrared Repeater Operation Manual CIR-03 & CIR-12...
- Page 2 Revision History Version No Date Summary of Change 20081113 Preliminary Release Precaution Failure to follow the precautions described below may cause damage to Infrared Extender and Repeater Box and void the warranty. DO NOT open the device, doing so will void the warranty. If you ...
-
Page 3: Table Of Contents
Table of Contents Introduction…………………………………………………..………. Applications………………………………..………………....…. Package Contents………………………………..…......… System Requirements…………………………..….…………..……. Features……………………………………………..……..……… Operation Controls and Functions………………...……..……… Front Panel ................Rear Panel …………………………………………..…….… Connection and Installation……………………………..……..… Specifications……………………………………..……...…………... -
Page 4: Introduction
Infrared Extender Box (CIR-03) Infrared Repeater Box (CIR-12) 1pc IR Eye Receiver cable (CIR-12) 5pcs IR Eye blaster cables (3pcs for CIR-03, 2pcs for CIR-12) 1pc 5V DC power supply adaptor Operation Manual 4. System Requirements Input source equipment connected with output displays through CAT 5 cable. -
Page 5: Operation Controls And Functions
① IR CAT5: Connect the CAT 5 cable to Infrared Extender Box with IR receiver. ② Power: Plug the 5VDC power supply into the unit and connect the adaptor to an AC outlet. Note: Only a power adapter is needed, connect the power adapter on either the CIR-03 or CIR-12. -
Page 6: Connection And Installation
7. Connection and Installation CIR-12 IR CAT5 CIR-03... -
Page 7: Specifications
8. Specifications Input Port 1 x IR receiver Output Ports 1 x CAT5 (CIR-03, CIR-12) 5 x IR extender (3 x CIR-03, 2 x CIR-12) Power Supply 2 x 5V/1A DC (US/EU standards, CE/FCC/UL certified for CIR-12.) Dimensions (mm) 62(W) x 50(D) x 23(H) - Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20081202 MPM-CIR03&CIR12...
