- Page 1 SPX-5600 Series Operations Manual Suprex® Reader Extender - RF Wireless Interface SPX-5600MAN Page 1 of 20...
- Page 2 Cypress Suprex SPX-5600 Series SPX-5600 Series: This manual covers the operation and setup of the Cypress Suprex RF SPX-5600 series units. Overview The SPX-5600 series of RF Wireless solutions provides a wireless bridge from Card Readers with gates or door hardware to most access control manufacturers panels.
- Page 3 External connections and DIP Switch Settings 1 - 8 to 16 VDC In 2 - Ground 1- Relay 4 N.O. SPX-5600 2- Relay 4 Com Status LED Central 3 - Relay 4 N.C. 4 - Relay 3 N.O. 1 - exp (+) 5 - Relay 3 Com 2 - exp (-) 6 - Relay 3 N.C.
- Page 4 Quick Reference For Typical Connections SPX-5600 Series Central Quick Reference D0/Clock D0/Clock Out D1/Data R1 IN D1/Data Out R1 Input LED In Controls Strike on Access Remote Control Switch #4 ON Panel Disable Pullup Resistors Switch #4 OFF Enable Pullup Resistors Diagnostic LED Ground 1 2 3 4 5 6 7 8...
- Page 5 Typical RF installation with repeater SPX-5601R (1) Obstruction SPX-5601C (1) SPX-5651 Typical RF installation - line of sight SPX-5601R (1) SPX-5601C (1) Typical RF installation - EXP-1000R (2) expansion modules EXP-1000R (3) SPX-5601C (1) SPX-5601R (1) Wiegand connection EXP-1000C (2) card reader EXP-1000C (3) RS-485 multi-drop...
- Page 6 Temperature Rating vs Voltage Derating Curve Ambient Temperature (Degrees Celsius) Supply Voltage Temperature/Voltage de-rating curve The Suprex units should be operated with a filtered 12 Volt nominal DC supply. Any voltage between 8 and 16 volts can be utilized by following the temperature /voltage derating curve.
- Page 7 Page left intentionally blank Page 7 of 20...
- Page 8 Cypress Suprex RF Series - Setup and Pre-installation Unpacking: Remove covers from units and check interior for any shipping damage. Remove any packing material if present. Inventory any included parts (depending on model) such as antennas, coax cables etc. Bench Testing: Before installing the units in the field they should be assembled and tested at a convenient “Bench top”...
- Page 9 Cypress Suprex RF Series - Indicators and Operating Modes LED Diagnostic Indicator: The LED Diagnostic indicator provides information on the operational status of the unit. If the units are not communicating, viewing the diagnostic indicator LEDʼs may help to determine the nature of the problem.
- Page 10 Cypress Suprex RF Series - Door Strike and LED I/O Note: The LED and Door Strike operation of the RF Suprex differs from previous Suprex versions. To activate the relay on the Remote unit, connect as shown below. These connections can be used to allow the Remote relay to operate a DOOR STRIKE, GATE, or other locking hardware.
- Page 11 Cypress Suprex 5600 Series - Door Strike and LED I/O The Cypress SPX-5600 provides additional data channels to support access control hardware such as door strikes, tamper alarms, request to exit status, etc. These signals are sent to and from the Remote and Central units without the need to run additional wiring.
- Page 12 Cypress Suprex Series - Relay Controls Input Signal Relay 1 IN Suprex Central Contact Outputs Relay 1 N.C Relay 1 Com Relay 1 N.O. Suprex Remote Page 12 of 20...
- Page 13 Cypress Suprex Series - Relay Controls Input Signal Relay 2 IN Suprex Central Contact Outputs Relay 2 N.C Relay 2 Com Relay 2 N.O. Suprex Remote Page 13 of 20...
- Page 14 Cypress Suprex Series - Relay Controls Contact Outputs Relay 3 N.C Relay 3 Com Relay 3 N.O. Suprex Central Input Signal Relay 3 IN Suprex Remote Relay 3 functions as an Alarm relay and monitors the condition of the communication link between the Central and Remote units.
- Page 15 Cypress Suprex Series - Relay Controls Contact Outputs Relay 4 N.C Relay 4 Com Relay 4 N.O. Suprex Central Input Signal (5Volts DC Maximum) Relay 4 IN Suprex Remote Page 15 of 20...
- Page 16 A site evaluation should have determined the optimal locations for the Central and Remote units, the type of antennas that would be needed, and the frequency band to be used. (See Cypress Application Note “Site Evaluation for Duprex RF products”).
- Page 17 Cypress Suprex RF Series - Field Installation This orientation may reduce range. The metal pole is placed between antenna and other unit and the antenna is close to metal. The units should be mounted in such a way that there is as clear of a path as possible between the 2 units.
- Page 18 RS232 Out +5 VDC Out RS232 In Prog Res 2 Ground Prog Res 1 Aux Out LED Input Relay2 Input D1/Data/F2F Out Relay1 Input D0/Clock Out Cypress Suprex Series - Wiegand Expansion Module Panel “Central” interface Page 18 of 20...
- Page 19 Cypress Suprex Series - Wiegand Expansion Module Reader/Door “Remote” interface D0/Clock In D1/Data In LED Out Card Reader Door R1 N.C. Strike R1 Com R1 N.O. Ground Power +8 to +16 VDC Supply 8 to 16 VDC In Ground RLY2 N.O.
- Page 20 Page left intentionally blank Page 20 of 20...
