Slim io Receiver Screen + Plug
6) Press the PROG button on the Somfy io-homecontrol® local
control point for ≈ 7 s until the motorised product moves up
and down twice.
The receiver is reset to its original configuration.

7. TECHNICAL DATA

Power supply
Index protection rating
Electrical insulation
Maximum number of associated control points
and sensors
Radio frequency
Frequency bands and maximum power used
Operating temperature
Number of operating cycles
Pollution index
Maximum power
Rated current
Rated impulse withstand voltage
Duty type
Switch type
Copyright © 2017 SOMFY ACTIVITE SA, Société Anonyme.. All rights reserved.
220 - 240 V / 50 Hz
IP 54
Class I
9
868-870 MHz io-homecontrol®, two-way
Tri-band
868.000 MHz - 868.600 MHz ERP < 25 mW
868.700 MHz - 869.200 MHz ERP < 25 mW
869.700 MHz - 870.000 MHz ERP < 25 mW
- 30 °C à + 70 °C
10000
2
690W
3A
2500V
S3
