5) When the motor arrives at its down end limit, press the "my"
button for at least 2 seconds.
The motorised product moves briefly.
Time of functioning = T(f) (Max = 4 min).
6) Go to § 4.5.

4.5. PROGRAMMING THE FIRST SOMFY IO LOCAL CONTROL POINT

4.5.1. Using a pre-programmed Somfy io local control point
• Briefly press the PROG button on this control point.
The motorised product moves briefly.
The control point is programmed.
4.5.2. After a power cut
1) Press the Up and Down buttons simultaneously on the new
control point until the motorised product moves.
2) Briefly press the PROG button on this control point.
The motorised product moves briefly.
The control point is programmed.

5. OPERATION AND MAINTENANCE

5.1. UP AND DOWN BUTTONS

Breifly press the Up or Down button to raise or lower the motorised
product fully.

5.2. STOP FUNCTION

The motorised product is moving.
• Briefly press the "my" button on the control point.
The motorised product stops automatically.

5.3. FAVOURITE POSITION (MY)

Besides the upper and lower positions, an intermediate position known as the "favourite position
(my)" may be programmed in the receiver.
5.3.1. Setting the favourite position (my)
1) Place the motorised product in the requested favourite position
(my).
2) Press the "my" button on the control button until the motorised
product moves.
The favourite position (my) has been programmed.
5.3.2. Using the favourite position (my)
• Briefly press the "my" button.
The motorised product starts to move, then stops. The
position of the motorised product then complies with the
favourite (my) position programmed.
