Slim io Receiver Screen + Plug
These instructions apply to all versions of the Slim io Receiver Screen + Plug, which are available in
the current catalogue.
CONTENTS
1. Introduction
1.1. Scope of application
1.2. Liability
2. Installation
2.1. Installation recommendations
2.2. Fitting the Slim io Receiver Screen + Plug 23
3. Wiring
4. Commissioning
4.1. Identifying setting steps already
completed
4.2. Pre-programming the Somfy io local
control point
4.3. Checking the motor's direction of rotation 25
4.4. Setting the time of functioning
4.5. Programming the first Somfy io local
control point
GENERAL
Safety instructions
Danger
Indicates a danger which may result in immediate death or serious injury.
Warning
Indicates a danger which may result in death or serious injury.
Precaution
Indicates a danger which may result in minor or moderate injury.
Attention
Indicates a danger which may result in damage to or destruction of the product.
Non contractual images.
Copyright © 2017 SOMFY ACTIVITE SA, Société Anonyme.. All rights reserved.
ORIGINAL INSTRUCTIONS
