3.3 Assignment of the DMX channels in the overview:

NOTE: Basic knowledge of the DMX512 control standard is required so that the device can be
correctly operated and Programed with a DMX controller.
5 Channel Mode:
DMX Mode Channel
1
2
3
5 CH
4
Value Description
000 - 255 Master Dimmer 0 - 100%
000 - 009 No Function
010 - 255 Stroboscope: slow → fast
000 - 009 No Function
010 - 019 RED
020 - 029 GREEN
030 - 039 BLUE
040 - 049 WHITE
050 - 059 AMBER
060 - 069 UV
070 - 079 YELLOW
080 - 089 MAGENTA
090 - 099 CYAN
100 - 109 DARK ORANGE
110 - 119 GREEN YELLOW
120 - 129 SALMON
130 - 139 TURQUISE
140 - 149 LIGHT GREEN
150 - 159 ORANGE
160 - 169 LAVENDER
170 - 179 LIGHT BLUE
180 - 189 DARK BLUE
190 - 199 PINK
200 - 255 No Function
000 - 009 No Function
010 - 019 Auto Program 1
020 - 029 Auto Program 2
030 - 039 Auto Program 3
040 - 049 Auto Program 4
050 - 059 No Function
060 - 069 Sound Program 1
070 - 079 Sound Program 2
080 - 089 Sound Program 3
Comments
Influences all
functions of CH3 and
CH4
Influences all
functions of CH3 and
CH4
