Commissioning
7.5

Configuration of the inputs

7.5.1 Configuration of the HART inputs
HART devices must be configured and given a unique HART address via their own user
interface before they are connected to the Proservo NMS8x.
Submenu: Setup → Advanced setup → Input/output → Analog I/O
Parameter Meaning / Action
Operating mode Select:
• HART master+4..20mA input if only one HART device is connected to this loop. In this case the
4-20mA signal can be used in addition to the HART signal.
• HART master if up to 6 HART devices are connected to this loop.
Submenu: Setup → Advanced setup → Input/output → HART devices → HART Device(s)
Parameter
Output pressure
Output density
Output temperature
Output vapor
temperature
Output level
1) There is a HART Device(s) submenu for each connected HART device.
52
Meaning / Action
• If the device measures a pressure: Select which of the HART variables (PV, SV, TV or QV)
contains the pressure.
• Otherwise: Keep the factory setting: No value
• If the device measures a density: Select which of the HART variables (PV, SV, TV or QV)
contains the density.
• Otherwise: Keep the factory setting: No value
• If the device measures a temperature: Select which of the HART variables (PV, SV, TV or
QV) contains the temperature.
• Otherwise: Keep the factory setting: No value
• If the device measures the vapor temperature: Select which of the HART variables (PV,
SV, TV or QV) contains the vapor temperature.
• Otherwise: Keep the factory setting: No value
• If the device measures a level: Select which of the HART variables (PV, SV, TV or QV)
contains the level.
• Otherwise: Keep the factory setting: No value
Proservo NMS80
1)
