Commissioning
7.6

Linking measured values to tank variables

Measured values must be linked to tank variables before they can be used in the Tank
Gauging application.
Depending on the application not all these parameters will be relevant in a given
situation.
Submenu: Setup → Advanced setup → Application → Tank configuration → Level
Parameter
Level source
Water level source
Submenu: Setup → Advanced setup → Application → Tank configuration → Temperature
Parameter
Liquid temp source
Air temperature source
Vapor temp source
Submenu: Setup → Advanced setup → Application → Tank configuration → Pressure
Parameter
P1 (bottom) source
P3 (top) source
56
Defines the source of the following tank variableTank variable
Product level
Bottom water level
Defines the source of the following tank variable
Average or spot temperature of the product
Temperature of the air surrounding the tank
Temperature of the vapor above the product
Defines the source of the following tank variable
Bottom pressure (P1)
Top pressure (P3)
