SOMFY Power 1 X 2,5 DC RTS Receiver Operating And Installation Manual page 9

C.3.d) Sun sensor operation :
The operational direction is set by default for
a motor installed at the top of the blind.
The operational direction can be programmed
for a product where the motor is installed at
the bottom of the blind.
To modify the direction:
Press the My and Up buttons for
approximately 2 seconds until the blind
moves up and down.
Press the Down button for approximately 2
seconds until the blind moves up and down
to set the Power 1x2,5DC RTS Receiver in
inverted sensor mode (in case motor is at the
bottom of the blind).
Press the Up button for approximately 2
seconds until the blind moves up and down
to set the Power 1x2,5DC RTS Receiver in
normal sensor mode (in case motor is at the
top of the blind).
Press the My button for approximately 2
seconds until the blind moves up and down
to confirm the sensor mode selection .
Copyright © 2009 Somfy SAS. All rights reserved - V0 - 09/2009 7
