D USE
D.1) My position :
The My position varies according to the type
of blind.
Venetian mode:
After adjusting the duration of up and down
motions, the My position is the following one :
lower position, slats position at about 45° (for
a Venetian with 25 mm slats and CTS 25).
The user can readjust this position.
Rolling mode:
After adjusting the duration of up and down
motions, the My position is the following one
3/4 closed.
The user can readjust this position.
Readjusting the position:
To readjust the My position the blind must
be in any position except the current My
position.
Venetian mode:
Press the My button for approximatly 5
seconds.
The blind goes to the existing My position.
Using the Up or Down buttons, or the scroll
wheel when using a Modulis remote control,
to readjust the My position.
Press the My button for approximately 2
seconds until the blind moves up and down.
The new My position is saved.
Rolling mode:
Using the Up or Down buttons select the new
desired position.
Press the My button for approximately 5
seconds until the blind moves up and down,
the new position is saved.
Deleting the position (for venitian or roller
mode):
By briefly pressing the My button take the
blind to the current My position.
Press the My button for approximately 5
seconds until the blind moves up and down.
The position has been deleted.
