C ADJUSTING THE BLIND
End limits are operated by the motor and its
accessories and not by the Power 1x2,5DC
RTS Receiver.
C.1) Connect the Power 1x2,5DC RTS
Receiver (It is necessary to take all the pre-
cautions of use to protect the Power 1x2.5DC
RTS Receiver from the electrostatic dischar-
ges).
If several motors are connected to the Power
2x0,75mm 2
1x2,5DC RTS Receiver, the adjustment will
be commun to all the motors.
2x0,25mm 2
C.2) Setting through the remote control:
Remark: When controlling through a
remote control, all Power 1 X 2,5 DC RTS
Receiver are adjusted at the same time if
several Power 1 X 2,5 DC RTS Receiver are
connected.
Pairing:
Briefly press the Up and Down buttons on the
remote control.
The blind moves up and down.
The remote control is temporarily saved.
Settings:
C3a C3b C3c C3d C3e
Refer to steps:
C3a: Choosing the type of blind :
C3b: Motor rotation direction :
C3c: Orientation using the dial :
C3d: Sun sensor operation :
C3e: Duration of raising and lowering of the
blind
Saving:
Briefly press the programming button on the
remote control.
The blind moves up and down.
The remote control is permanently saved.
