C.3.e) Timer setting for raising and lowering the
blind:
1) Take to upper end-stop of the blind. The blind
automatically stops at the mechanical end-stop.
2) Briefly press the My and Down buttons: the
end-product lowers (for 10 seconds) and stops.
You can stop the blind prior to the 10 seconds by
pressing the Stop button.
3) If the blind is not at its lowest position, press the
Down button until the blind reaches
the lowest position set mechanically. The blind
lowers as long as the button is pressed and held
for a maximum duration of 10 seconds.
Nb: Only the length of time the button is held is
saved. Time is not measured once the blind is
stopped.
4) Once the end-product is at the lowest position
release the Down button.
Nb: If the Down button remains held as the
mechanical stops down position is reached, time
continues to be measured and the blind does not
move.
5) Briefly press the My and Up buttons: The
endproduct
rises (for 10 seconds) and stops. You can
stop the blind prior to the 10 seconds by pressing
the Stop button.
Nb: Pressing the My and Up buttons confirms the
down motion duration.
6) If the blind is not at its upper position, press
the Up button until the blind reaches the upper
position set mechanically. The blind rises as long
as the button is pressed and held for a maximum
duration of 10 seconds.
Nb: Only the length of time the button is held is
saved. Time is not measured once the blind is
stopped.
7) Once the end-product is at the upper position
release the Up button.
Nb: If the Up button remains held as the mecha-
nical
stops up position is reached, time continues to
be measured.
8) To finalize the setting of up and down motion
duration, press the My button for approximately
2 seconds until the blind moves up and down.
Durations are confirmed,
saved and a favorite position (My) is automatically
set.
8 Copyright © 2009 Somfy SAS. All rights reserved - V0 - 09/2009
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
