Tubular motor:
GEIGER-SOLIDline
GEIGER-SOLIDline ../55
Motor control:
GEIGER-Easy-ZIP 1.x, 2.x and 3.x (GU45.. E10)
for screens with ZIP guidance
Original-Montage- und
DE
Betriebsanleitung
Original assembly and
EN
operating instructions
Notice originale de montage
FR
et d'utilisation
Instrucciones originales de
ES
instalación y funcionamiento
Istruzioni originali di installazione
IT
e funzionamento
www.geiger.de
EN
1
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GEIGER GEIGER-SOLIDline Series
Summary of Contents for GEIGER GEIGER-SOLIDline Series
- Page 1 Tubular motor: GEIGER-SOLIDline GEIGER-SOLIDline ../55 Motor control: GEIGER-Easy-ZIP 1.x, 2.x and 3.x (GU45.. E10) for screens with ZIP guidance Original-Montage- und Betriebsanleitung Original assembly and operating instructions Notice originale de montage et d’utilisation Instrucciones originales de instalación y funcionamiento Istruzioni originali di installazione e funzionamento www.geiger.de...
-
Page 2: Table Of Contents
1. General information Dear customer, By purchasing a Geiger motor you have decided on a quality product from Geiger. Thank you very much for your decision and the confidence placed in us. Before you put this drive into operation please observe the following safety instructions. It serves for the prevention of danger and for the avoidance of personal injury and damage to property. -
Page 3: Intended Use
GU 45 Motor control Torque in Nm Motor diameter Geiger universal drive 4. Safety instructions ATTENTION: Important safety instructions. For personal safety, it is important to follow these instructions. Please keep these instructions for future reference. f Do not allow children to play with stationary controls. Keep remote controls away from children. -
Page 4: Safety Instructions For Assembly
A plug for the disconnection of the motor from the power supply must be accessible after installation. f Damaged connecting cables must be replaced by Geiger connecting cables of the same type. f The device must be mounted as described in the installation instructions. Fixations shall not be made with adhesives since they are regarded as unreliable. -
Page 5: Installation Instructions
– Place the motor into the existing engine bearer and lock – Place the motor in a compatible engine bearer with clip system and lock with spring or rotating lever The Geiger-SOLIDline motor is suitable for shaft diameters from 50 mm! www.geiger.de... -
Page 6: Information For The Specialist Electrician
Article Number / Geiger setting switch M56F152 with service terminal (D), 5 wires, SMI compatible M56F153 with service terminal (CH), 5 wires, SMI compatible M56F154 with service terminal (D), 4 wires Gerhard Geiger GmbH & Co. KG | 100W1552 V000 1118... -
Page 7: Control Options
Lower and upper end position: torque shutoff Dual-Stop-Control Hanging length adjustment Less charge in the upper end position Geiger Powertronic (power level) Geiger locking force reduction 10. Setting of the end positions with Easy-ZIP 1.x Following installation types are possible: Screen is equipped with:... - Page 8 Press the programming key or the UP and DOWN keys at the same time until the motor confirms (3 x click-click). The upper end position is now stored. The programming is completed and the motor returns to normal mode. Gerhard Geiger GmbH & Co. KG | 100W1552 V000 1118...
- Page 9 Press the programming key or the UP and DOWN keys at the same time until the motor confirms (3 x click-click). The upper end position is now stored. The programming is completed and the motor returns to normal mode. www.geiger.de...
- Page 10 • Learning mode for end positions activated 2 x click-click • Storing of the lower end position is confirmed 3 x click-click • Storing of the upper end position is confirmed Gerhard Geiger GmbH & Co. KG | 100W1552 V000 1118...
-
Page 11: (Qi Mode)
4. The screen moves now automatically to the upper end position. When the screen has reached the upper position the motor shuts off. The programming procedure is then completed and the motor returns to normal operating mode. Motor feedback Easy-ZIP 3.x 1 x click-click • Learning mode for end positions activated www.geiger.de... -
Page 12: Obstacle Detection
These are estimated values so please check the correct functioning of the installation. When using a wind sensor the correct functioning of the retract command under wind load should be checked by the manufacturer of the sun protection before commissioning. Gerhard Geiger GmbH & Co. KG | 100W1552 V000 1118... -
Page 13: Deactivating The Obstacle Detection In Down Direction
After running several times, • The motor became too hot and has the motor breaks down and switched off. no longer responds. Try it again after a cooling time of about 15 min. 18. Maintenance The drive is maintenance-free. www.geiger.de... -
Page 14: Declaration Of Conformity
Gerhard Geiger GmbH & Co. KG Schleifmühle 6 | D-74321 Bietigheim-Bissingen Phone +49 (0) 7142 9380 | Fax +49 (0) 7142 938 230 | info@geiger.de | www.geiger.de Sitz Bietigheim-Bissingen | Amtsgericht Stuttgart HRA 300591 | USt-IdNr. DE145002146 Komplementär: Geiger Verwaltungs-GmbH | Sitz Bietigheim-Bissingen | Amtsgericht Stuttgart HRB 300481 Geschäftsführer: Roland Kraus | WEEE-Reg.-Nr. -
Page 15: Technical Data For Solidline Motors With 16 Revolutions Per Minute
The average sound pressure level data are intended for guidance only. The values were determined by Geiger at a distance of 1 m, with a hanging motor at idle speed and averaged over 10 seconds. There is no reference to any specific test standard. -
Page 16: En 22. Notes On Waste Disposal
They will be happy to assist you. Gerhard Geiger GmbH & Co. KG Schleifmühle 6 | D-74321 Bietigheim-Bissingen T +49 (0) 7142 9380 | F +49 (0) 7142 938 230 info@geiger.de | www.geiger.de Gerhard Geiger GmbH & Co. KG | 100W1552 V000 1118...
