Tubular motor:
GEIGER-SOLIDline ../55
Motor control:
GEIGER-SoftZeroWireless-55 (GU45..F02)
for facade awnings, screens and ZIP screens
GEIGER-SoftWireless-55 (GU45..F02)
for side awnings
DE
Bedienungsanleitung
EN
Operating Instructions
FR
Manuel d'utilisation
Manual de instrucciones
ES
IT
Istruzioni per l'uso
www.geiger.de
EN
1
EN
Advertisement
Table of Contents
Related Manuals for GEIGER GEIGER-SOLIDline x/55 Series
Summary of Contents for GEIGER GEIGER-SOLIDline x/55 Series
- Page 1 Tubular motor: GEIGER-SOLIDline ../55 Motor control: GEIGER-SoftZeroWireless-55 (GU45..F02) for facade awnings, screens and ZIP screens GEIGER-SoftWireless-55 (GU45..F02) for side awnings Bedienungsanleitung Operating Instructions Manuel d’utilisation Manual de instrucciones Istruzioni per l’uso www.geiger.de...
-
Page 2: Table Of Contents
14. End position correction ..........13 15. Technical data ..............13 16. Notes on waste disposal ..........13 17. Information for the specialist electrician .....14 18. Declaration of conformity ..........14 19. What to do if… ..............15 Gerhard Geiger GmbH & Co. KG | 100W0595 V001 0818... - Page 3 Radio-controlled motor for facade awnings and side awnings • Facade awnings, screens and ZIP screens can be operated with the GEIGER SoftZeroWireless-55 • The GEIGER-SoftWireless-55 is designed exclusively for the operation of side awnings Safety • A safe locking of the casing through torque shutoff Fabric Protection •...
-
Page 4: General Information
1. General information Dear customer, By purchasing a GEIGER tubular motor you have decided on a quality product from GEIGER. Thank you very much for your decision and the confidence placed in us. Before you put this drive into operation please observe the following safety information. -
Page 5: Intended Use
If the tubular motors are used for other applications and/or modifications are performed to the tubular motors, which have not been discussed with GEIGER Antriebstechnik, then the manufacturer is not liable for personal injury and/or damage to property and for consequential damage. -
Page 6: Installation Instructions
Definition of „far range“: Distance of the hand-held transmitter to the motor control: min.1.5 metres, Distance of the hand held transmitter to the motor min. connecting cable min.0.5 metres 1,5 m Gerhard Geiger GmbH & Co. KG | 100W0595 V001 0818... -
Page 7: Learning/Deleting The Radio Code
5 seconds. The motor reacts immediately max. 15 cm (1 x ‘Click-Click’). Please note: about 5 sec. You can only delete all remote codes and sensor remote codes together. It is not possible to delete individual remote codes. www.geiger.de... -
Page 8: Adjustment Of The End Positions
Saving the lower end position: click From close range, press the up or down button and hold approx. 1 second, then release. The motor responds (1 x ‘Click-Click’). max. 15 cm approx. 1 sec. Gerhard Geiger GmbH & Co. KG | 100W0595 V001 0818... -
Page 9: Side Awnings Operation
• GEIGER-hand-held remote, which is taught-in in accordance with Chapter 7 (page 7). Please note: • The end positions are not affected when the GEIGER-Powertronic is activated. • Only activate the GEIGER-Powertronic after the end positions have been taught- in and a complete trial has been conducted. - Page 10 (2 x ‘Click-Click‘). Should there be no activity for 60 seconds, max. 15 cm learning mode will be deactivated. The power level set will be assumed! approx. 1 sec. Gerhard Geiger GmbH & Co. KG | 100W0595 V001 0818...
-
Page 11: Function Description Of Radio Motor
In the delivery state, each GEIGER radio receiver and radio transmitter is equipped with the “GEIGER-Code“ + + + + - + - so that the motor can be operated immediately, in order, for example, to facilitate the installation of hangings on the winding shaft. -
Page 12: Obstacle Recognition
11,0 13,2 11,6 14,0 12,3 14,7 10,8 13,5 16,2 3 Nm 6 Nm 9 Nm 12 Nm These are estimated values so please check the correct functioning of the installation. Gerhard Geiger GmbH & Co. KG | 100W0595 V001 0818... -
Page 13: End Position Correction
Waste disposal of electric and electronic equipment Electronic equipment or batteries cannot be discarded along with the normal household waste. Keep for more information on the recycling and disposal methods envisaged by the local regulations in your area. www.geiger.de... -
Page 14: Information For The Specialist Electrician
It is authorised for use in all EC member states and in Switzerland without any need of prior registration. The Declaration of Conformity concerning this product is available on our website: www.geiger-antriebstechnik.de. Gerhard Geiger GmbH & Co. KG | 100W0595... -
Page 15: What To Do If
The motor stops between the upper • The motor has detected an obstacle. and the lower end stop. Please remove the obstacle. The device will be unlocked if the motor is run for a short time period in the opposite direction. www.geiger.de... -
Page 16: En Gerhard Geiger Gmbh & Co. Kg | 100W0595 En V001
They will be happy to assist you. Gerhard Geiger GmbH & Co. KG Schleifmühle 6 D-74321 Bietigheim-Bissingen Telephone: +49 (0) 7142 938-0 Telefax: +49 (0) 7142 938-230 E-Mail: info@geiger.de Internet: www.geiger.de Gerhard Geiger GmbH & Co. KG | 100W0595 V001 0818...
