    1. General information Dear customer, By purchasing a Geiger motor you have decided on a quality product from Geiger. Thank you very much for your decision and the confidence placed in us. Before you put this drive into operation please observe the following safety instructions. It serves for the prevention of danger and for the avoidance of personal injury and damage to property.
  • Page 3: Safety Instructions

    The height of installation must be at least 1.5 m above the floor. f Permanently installed control devices must be attached visibly. f In case of devices extending horizontally, a horizontal distance of at least 0.4 m must be respected between the fully extended part and any other fixed element. www.geiger.de...
  • Page 4: Assembly Note

    A plug for the disconnection of the motor from the power supply must be accessible after installation. f Damaged connecting cables must be replaced by Geiger connecting cables of the same type. f The device must be mounted as described in the installation instructions. Fixations shall not be made with adhesives since they are regarded as unreliable.
  • Page 5: Installation Instructions

    7. Installation instructions Prior to installation please check to ensure there is no visible damage to the motor like cracks or open cables. Before fixing please check the strength of the masonry and of the  surface. www.geiger.de...
  • Page 6: Information For The Specialist Electrician

    Geiger setting switch e5: the setting can be realized with any switch allowing simultaneous UP and DOWN controls.
  • Page 7: Setting Of The End Stops

    10. Setting of the end stops Motors GF56..e1 – e4: a Geiger setting switch is required for the setting of the end stops Motors GF56..e5: the setting can be realized with any switch allowing simultaneous UP and DOWN commands. Part-Nr. / Geiger setting switch...
  • Page 8 When using an external setting switch, the UP and DOWN keys must be activated simultaneously – instead of the programming key. Instead of the lighting up of the LED, the motor reacts with a short back and forth movement. Gerhard Geiger GmbH & Co. KG | 100W1503 V001 1118...
  • Page 9: Operation

    Try it again after a cooling time of about 15 min. After setting of the lower end position the • The motor has been installed upside down blind only runs in DOWN direction. (see assembly note). 13. Maintenance The drive is maintenance-free. www.geiger.de...
  • Page 10: Technical Data

    The average sound pressure level data are intended for guidance only. The values were determined by Geiger at a distance of 1 m, with a hanging motor at idle speed and averaged over 10 seconds. There is no reference to any specific test standard.
  • Page 11: Declaration Of Conformity
