  • Page 1 Operating instructions Tubular motor: GEIGER-Solid Line Motor control: GEIGER-Easy (GU45..E01) for rolling shutters and screens Bedienungsanleitung Operating Instructions Manuel d’utilisation Manual de instrucciones Istruzioni per l’uso...
  • Page 2: Table Of Contents

    10. What to do if ......E12 GEIGER Antriebstechnik GmbH | 100W0518 en 1110...
  • Page 3: General Information

    1. General information Dear customer, By purchasing a GEIGER tubular motor you have decided on a quality product from GEIGER. Thank you very much for your decision and the confidence placed in us. Before you put this drive into operation please observe the following safety informa- tion.
  • Page 4: Safety Information

    The installation is to be checked regularly for defective balance, wear and damage. Damaged connecting leads must be replaced by the GEIGER connecting lead of the same wire type. During operation observe the danger zone. If people or objects are in the danger zone, do not use the installation.
  • Page 5: Stop

    If the tubular motors are used for other applications and/or modifications are per- formed to the tubular motors, which have not been discussed with GEIGER Antriebstechnik, then the manufacturer is not liable for personal injury and/or damage to property and for consequential damage.
  • Page 6: Gb 5. Installation Instructions

    Screw together shaft with tubular carrier. Fix rolling shutter casing to shaft. Alternative: use fixation plates for external alumi- nium shuters in order to fix the motor. The bearer locks into place. For removal, turn spring ring. GEIGER Antriebstechnik GmbH | 100W0518 en 1110...
  • Page 7 Alternative: - Fix motor with the suitable screws (M6 or M8), depending on the size of the divided circle, to the awning support - Put motor into awning support using a square box wrench and secure with split pin. www.geiger-antriebstechnik.de...
  • Page 8: Adjustment Of The End Positions

    Then press the programming key until the LED lights permanently, then release the programming key. The lower end position is adjusted here und the adjustment process is finished. 5. The drive can now be connected to the 230V mains. GEIGER Antriebstechnik GmbH | 100W0518 en 1110...
  • Page 9: Stop

    The running direction in which the obstacle was recognized is blocked. The block is removed if the motor has been operated in the opposite direction for a certain time. An obstacle must thus first be released before the motor can be operated again in the direction of the obstacle. www.geiger-antriebstechnik.de...
  • Page 10: Technical Data

    2004/108/EC. It is authorised for use in all EC member states and in Switzerland without any need of prior registration. The Declaration of Conformity concerning this product is available on our website: www.geiger-antriebstechnik.de. GEIGER Antriebstechnik GmbH | 100W0518 en 1110...
  • Page 11: Information For The Specialist Electrician

    Waste disposal of electric and electronic equipment Electronic equipment or batteries cannot be discarded along with the normal hou- sehold waste. Keep for more information on the recycling and disposal methods envisaged by the local regulations in your area. www.geiger-antriebstechnik.de...
  • Page 12: What To Do If

    For technical questions, please call our service team at: +49 (0) 7142 938-300 They will be happy to assist you. Gerhard Geiger GmbH & Co. Schleifmühle 6 D-74321 Bietigheim-Bissingen Telephone: +49 (0) 7142 938-0 Telefax: +49 (0) 7142 938-230 www.geiger-antriebstechnik.de info@geiger-antriebstechnik.de GEIGER Antriebstechnik GmbH | 100W0518 en 1110...
