B.4
INSTALLING OPTIONAL HIGH SPEED INTERFACE MODULES
Figure B-4 shows the location of the connector for an optional High Speed Interface Module
(HSIM).
Refer to the installation instructions for the optional HSIM in the associated user's guide.
NOTE
NOTE
NOTE
NOTE
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Installing Optional High Speed Interface Modules
Optional HSIM
HSIM Connector
Figure B-4 HSIM Connector Location
Optional Installations and Mode Switch Bank Settings
DRAM
2693_93
B-5
