Cabletron Systems 6E233-49 SmartSwitch 6000 User Manual page 43

Using LANVIEW
Table 4-1 LANVIEW LEDs CPU, Receive, and Transmit Status (Continued)
LED Color State
TX Off Port enabled, and no activity.
Should flash green every two
seconds indicating BPDUs
being sent if STA is enabled
and there is a valid link.
Green Flashing. Indicates activity.
Rate indicates data rate.
Amber Blinking. Port in standby. Port
may be disabled due to
Spanning Tree.
Red Flashing. Indicates collision
rate.
Solid. Diagnostic Failure.
4-4 Troubleshooting
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Recommended Action
1. Ensure that the STA is enabled and
that there is valid link. The Local
Management User's Guide describes
how to enable the STA.
2. Contact Cabletron Systems.
None.
1. Ensure that the port is not disabled.
Refer to the Local Management
User's Guide for information on
enabling/disabling ports.
2. Contact Cabletron Systems.
None, unless there is a high rate of
activity. If so, check for network
configuration problems or a defective
device.
Contact Cabletron Systems.
