SIMM Upgrade
B.3.2

Installing the DRAM SIMM

Observe all antistatic precautions when handling sensitive electronic equipment.
!
CAUTION
To install a DRAM SIMM, refer to
1. With the SIMM alignment notch oriented as shown in
between the connector teeth.
2. Pivot the SIMM downward so the connector clips align with the two side notches of the SIMM
and the connector clips lock the SIMM into place.
Side Notch
B-4 Optional Installations and Mode Switch Bank Settings
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Figure B-3 and proceed as follows:
Connector
Connector
Clip
2
SIMM
Figure B-3 Installing the DRAM
Figure B-3, insert the SIMM down
Teeth
1
Clip
Alignment Notch
Side Notch
2504-91
