3. Locate the antistatic wrist strap shipped with the 6C105 chassis. Attach the antistatic wrist strap
to your wrist and plug the cable from the antistatic wrist strap into the ESD grounding
receptacle at the upper right corner of the 6C105.
4. Remove the module from the plastic bag. (Save the bag in the event the module must be
reshipped.) Observe all precautions to prevent damage from Electrostatic Discharge (ESD).
5. Examine the module for damage. If any damage exists, DO NOT install the module.
Immediately contact Cabletron Systems. Refer to
To prevent damaging the backplane connectors in the following step, take care that the
!
module slides in straight and properly engages the backplane connectors.
CAUTION
In the following step, ensure that the top plastic locking tab lines up with the desired slot
NOTE NOTE
NOTE NOTE
number located on the front panel of the chassis. Refer to
6. Locate the slot guides that line up with the number of the slot in which the module will be
installed. Install the module in the chassis by aligning the module circuit card between the upper
and lower metal rail guides of the desired slot, sliding it into the chassis, and locking down the
top and bottom plastic locking tabs, as shown in
straight and properly engages the backplane connectors.
7. If the chassis in which the module is installed was powered down for the installation, turn it
back on. Check to see that the CPU LED settles at solid green after a few minutes. If the LED
does not turn solid green, refer to
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Installing the 6E233-49 SmartSwitch into the 6C105 Chassis
Section 1.2.
Figure 3-1. Take care that the module slides in
Chapter 4 for details.
Figure 3-1.
Installation 3-3
