Installing Options

.
Table 3-1 Contents of 6E233-49 SmartSwitch Carton
3.3 INSTALLING OPTIONS
If the 6E233-49 SmartSwitch is to be installed with an optional HSIM, refer to the installation
instructions shipped with the HSIM. The HSIM must be installed before the 6E233-49 is installed
in the chassis.
3.4 INSTALLING THE 6E233-49 SMARTSWITCH INTO THE 6C105
CHASSIS
Failure to observe static safety precautions could cause damage to the 6E233-49
!
SmartSwitch. Follow static safety handling rules and properly wear the antistatic wrist
CAUTION
strap provided with the 6C105 chassis.
The 6E233-49 SmartSwitch can be installed in any of the 5 slots that are available in the 6C105. To
install a module, proceed as follows:
1. Remove the blank panel covering the slot in which the module will be installed. All other slots
must remain covered to ensure proper air flow and cooling. (Save the blank plate in the event
you need to remove the module.)
2. Carefully remove the module from the shipping box. (Save the box and packing materials in the
event the module must be reshipped.)
Do not cut the non-conductive bag to remove the module. Damage could result from
!
sharp objects contacting the board or components.
CAUTION
3-2 Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Item
2H252-25
Antistatic Wrist Strap
RJ21 Adapter/Extender
Release Notes
Manual Accessory Kit
Quantity
1
1
4
1
1
