This chapter provides information concerning the following:
• Using the LANVIEW diagnostic and status monitoring system
• Troubleshooting network and module operational problems
• Using the RESET button
4.1

USING LANVIEW

The 6E233-49 SmartSwitch uses Cabletron Systems' built-in visual diagnostic and status
monitoring system called LANVIEW. The LANVIEW LEDs
of the network status to aid in diagnosing network problems. Refer to
the LEDs.
Refer to the HSIM user's guide for a description of the HSIM LEDs.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
(Section 4.3)

Troubleshooting

(Section 4.1)
(Section 4.2)
(Figure 4-1) allow quick observation
Table 4-1 for a description of
Troubleshooting
4
4-1
