The terms flashing, blinking, and solid used in the LED definition tables of this
NOTE NOTE NOTE NOTE
chapter indicate the following:
Flashing indicates an irregular LED pulse.
Blinking indicates a steady LED pulse, (approximately 50% on, 50% off).
Solid indicates a steady LED light. No pulsing.
Table 4-1 LANVIEW LEDs CPU, Receive, and Transmit Status
LED Color State
CPU Off Power off.
Red Blinking. Hardware failure
has occurred.
Solid. Resetting, normal
power up reset.
Amber Blinking. Crippled.
Solid. Testing.
Green Solid. Functional.
Amber Booting. Blinks amber and
and green while booting.
Green
RX Off No link. No activity. Port
enabled or disabled.
Green Solid. Port enabled, link, no
activity.
Blinking. Port disabled, link.
Amber Flashing. Port enabled, link,
activity.
Red Diagnostic failure.
