Using the RESET Button

4.3 USING THE RESET BUTTON
The RESET button, located near the upper plastic locking tab of the module (refer to
resets the 6E233-49 SmartSwitch processor without affecting the NVRAM.
Pressing the RESET button resets the device, and all current switching being
!
performed by the module is halted. A module downtime of up to two minutes
CAUTION
results from this action.
To reset the 6E233-49 SmartSwitch processor, press and release the RESET button. The module
processor goes through a reset process of approximately 20 seconds. Additional downtime may be
added as the module reenters the network.
It is not recommended to press the RESET button while the module is already in
NOTE NOTE NOTE NOTE
reset mode. The module will enter an extended diagnostic procedure, which is
unnecessary for normal operation. This procedure will take much longer than a
minute. The ESC key can be used to exit the procedure.
4-10 Troubleshooting
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
ETHERNET
6E233-49
RESET
Button
RESET
COM
CPU
12
Figure 4-2 RESET Button
Figure
36
26931_10
4-2),
