4.80 H SST - 4.300 H SST
Automotive lift date: 10/2003
Manual date: 24.10.2003
Operating Instruction and Documentation
Serial number: .....................................
retailer/ phone
Nußbaum Hebetechnik GmbH & Co.KG//Korker Straße 24//D-77694 Kehl-Bodersweier//Tel: +49(0)7853/8990
Fax: +49 (0)7853/8787//E-mail: info@nussbaum.lifts.de//http://www.nussbaum-lifts.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4.250 H SST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nussbaum 4.250 H SST

Summary of Contents for Nussbaum 4.250 H SST

  • Page 1 4.80 H SST - 4.300 H SST Automotive lift date: 10/2003 Manual date: 24.10.2003 Operating Instruction and Documentation Serial number: ........retailer/ phone Nußbaum Hebetechnik GmbH & Co.KG//Korker Straße 24//D-77694 Kehl-Bodersweier//Tel: +49(0)7853/8990 Fax: +49 (0)7853/8787//E-mail: info@nussbaum.lifts.de//http://www.nussbaum-lifts.de...

  • Page 2: Table Of Contents

    6.2.1 Procedure of the emergency lowering ..............19 6.3 Reset the lift after an emergency lowering ..............21 7.Inspection and Maintenance of Nussbaum lifts ..............22 7.1 Maintenance plan of the Mobile column lift..............22 7.2 Cleaning of the Mobile column lift................. 23 8.Security check ........................

  • Page 3: Foreword

    Another or the described purpose going out use is not valid when not as agreed. This is valid particularly for climb and go. Company Nussbaum is not liable for damages arising from this. The user carries the risk a lonely.
  • Page 4 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Organising requirements The instructions for use are constantly to be kept at the place of operation being at hand at any time. In addition to the instructions for use rules pertaining to other regulations i.e. accident prevention and environmental rules are to be observed and directed.

  • Page 5: Record Of Installation

    4.80 H SST- 4.300 H SST Filling out and undersigned and copying this sheet and send the original to the lift manufacturer. The copy remains in the Manual. Otto Nussbaum Hebetechnik GmbH & Co. KG Korker Straße 24 D-77694 Kehl-Bodersweier Record of installation The automotive lift 4.80 H SST –...

  • Page 6: Record Of Handing Over

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Record of handing over The automotive lift 4.80 H SST – 4.300 H SST with the serial number:..........was installed on:..........at the firm:..........at:..............the safety was checked and the lift was started. The persons below were introduced after the installation of the automotive lift.

  • Page 7: Introduction

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 1.Introduction The document ”Operating Instructions and Documentation” contains important information about installation, operation and maintenance of the automotive lift. To furnish proof of installation of the automotive lift the form ”Record of Installation” must be signed and returned to the manufacturer.

  • Page 8: Master Document Of The Automotive Lift

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 2.Master document of the automotive lift 2.1 Lift–manufacturer Otto Nußbaum Hebetechnik GmbH & Co. KG Korker Straße 24 D-77694 Kehl-Bodersweier Germany 2.2 Application The automotive lift 4.80 H SST – 4.300 H SST is a lifting mechanism for lifting motor vehicles with a laden weight of up to 8000 kg –...

  • Page 9: Ce-Certificate

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 2.5 CE-Certificate - 9 -...
  • Page 10 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 10 -...

  • Page 11: Technical Information

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 3. Technical Information 3.1 Technical ratings Capacity: *after implementation 8000 kg - 30.000 kg Lifting time approx. 100 sec. with load (*) Lowering time approx. 55 sec. with load Line voltage 3 x 400 Volt , 50Hz Control voltage 24 V...
  • Page 12 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST If the lift descends noticeable faster there may be a problem with the hydraulic system. The computer-control-system recognizes the problem and switch off the hydraulic supply for the cylinder. The Safety-star system locks and the lift stopped. - Switch off the main switch.

  • Page 13: Data Sheet

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 3.3 Data sheet - 13 -...

  • Page 14: Foundation Diagram Drawing

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 3.4 Foundation diagram drawing Bei Erstellung des Fundamentes ist die unbedingt die Schienenlänge zu prüfen. Check the length before construction the foundation. - 14 -...

  • Page 15: Safety Regulations

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 4. Safety regulations Using automotive lifts for working the regulations of accident EN1493/Aug.98 (CEN/TC 98 „ Automotive lifts”) must be observed. Especially the following regulations are very important: • During working with the lift the operating instructions must be followed. •...

  • Page 16: Operating Instructions

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 5. Operating instructions The Safety Regulations must be observed during working with the automotive lift. Read the safety regulations in chapter 4 carefully before working with the lift! 5.1 Lifting the vehicle •...

  • Page 17: Equalisation Of The Lift

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Control the dangerous places of the lift and be sure that there are no objects or people in the immediate area of the lift or on the lift. Press the button “Lowering”...

  • Page 18: Troubleshooting

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST In this case it is possible to lower the lift with the button „lowering and the bypass switch. Press both buttons simultaneously (see pic 2, arrow) until the lift has the normal function again.

  • Page 19: Remove An Obstacle

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 6.1.1 Remove an obstacle Only trained and authorized staff is allowed to work with the DIP-switches! The main-switch has to be switched off! • Remove the cover of the operating unit and the control box. •...
  • Page 20 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Pic 7: The piston rod can be stuck through the dirty deposit at the top of the hole. Use the solvent and lubricating stuff (for an example WD40) to loosen the connection. The WD40 is sprayed generously between the screw thread and the bore hole (see arrow).

  • Page 21: Reset The Lift After An Emergency Lowering

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST You can only work again with the automotive-lift, if it is in a safety-related perfect condition. • After it, carry out an reset as described in the operating instruction. 6.3 Reset the lift after an emergency lowering A reset of the system can be enforced, if the Mobile column lift are in the lowest position.

  • Page 22: Inspection And Maintenance Of Nussbaum Lifts

    • Check the Battery of the controller (ASC). The Battery has a working life between 4 ½ - 5 Years. To avoid a permanent data-loss through an empty battery, the ASC must be sent for after 4 years into the Nussbaum headquarter. Please contact your service partner.

  • Page 23: Cleaning Of The Mobile Column Lift

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST pic 6: 7.2 Cleaning of the Mobile column lift A regular and appropriate maintenance served the preservation of the lift. It can be a prerequisite for claims at possible corrosion. The best protection for the lift is the regular cleaning of dirt of all manner.

  • Page 24: Security Check

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 8.Security check The security check is necessary to guarantee the safety of the lifting during use. It has to be performed in the following cases: 1. Before the initial operation, after the first installation Use the form “First security check before initiation”...
  • Page 25 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST • An electrical supply 3~/N+PE, 400 V, 50 Hz has to be provided. The supply line must be protected with T16A (VDE0100 German regulation). The minimum diameter amounts to 2,5 mm². •...

  • Page 26: Adjusting The Rail

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST chosen according to picture 9. If the ground is covered with floor tiles, the dowels have to be chosen according to picture 10. • Check the position of the columns again. If there is an uneven floor even it with metal sheets.

  • Page 27: Initiation

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST • Disconnect the power supply and the plugs under the platforms. • Refill the oil. • Loose the dowels. • Loose the crossbeam and remove it. • Transport the lift to the new installation place. •...
  • Page 28 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST pic. 9 choice of the dowel length without floor pavement or tile surface Table to pic. 9 Liebig-dowels Dowel type B15/75 B15/95 Drilling depth Min. anchorage depth Thickness of concrete Diameter of bore Thickness of the lift-pieces e 0-40...
  • Page 29 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST pic 10: choice of the dowel length with floor pavement or tile surface Table to pic. 10 Liebig-dowels Dowel type B15/70 B15/95 B15/120 B15/145 Drilling depth Min. anchorage depth Thickness of concrete Diameter of bore Thickness of the lift-pieces e 0-40...

  • Page 30: First Security Check Before Installation

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST First security check before installation Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation....................
  • Page 31 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 32 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 33 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 34 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 35 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 36 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 37 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 38 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Regular security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 39 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Extraordinary security check Filling out and leave in this manual defect veri- kind of check right missing fication remark ---------------------------------------------------------------------------------------------------------------------------------------- Type plate......................Short operating instruction................... Warning designation.................... Sticker “max.
  • Page 40 50.3 –E- Gleichlauffehler Only when a such mistake was caused, should after telephonic consultation with the Fa. Nussbaum, phone, 0049 (0)7853-899-0 the service-functions, (sees section 4 (service-operating) become used. With full function-willingness of the automotive-lift, the operating of the service - functions, over the foil-keyboard is forbidden.
  • Page 41 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 3. Elapsed time indicator-ad The number of the working hours can be extract through the operating. Press the button < * > on the foil-keyboard of the lift. Ad of the working hours in hours: minute Betriebsstunden Only the time is counted, in which the lift 0000000:00 h...
  • Page 42 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST 4.2 Service-Menu >Gesteuert< Dialed menu-point becomes through > < marked Achse nullen Hubhöhe zurück Function button: < * > next menu-point dials < #> menu-point activates The menu-point becomes >zurück < activated jumps back this to the position-ad. 4.3 STEERED Both axes of the lift can be driven individually over the function "...
  • Page 43 Over this function, the entire measuring-system of the lift can be put back, (zero). This function is allowed to only after consultation with the service-headquarters of the Fa. Nussbaum (phone) + 49 (0)7853-899-0. Achse nullen? Alert message, whether axes should really become reset.

  • Page 44: Hydraulic Diagram Drawing

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Hydraulic diagram drawing - 44 -...
  • Page 45 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Hydraulic parts list Pos. Description order number oil tank oil filter 980012 gear pump 980486 suboilmotor 991033 oil level gauge 980098 hydraulic block complete 99 540 06 00 5 pressure relief valve 230 bar 155211 pressure relief valve...

  • Page 46: Electrical Diagram Drawing

    Operating Instruction and Documentation 4.80 H SST- 4.300 H SST Electrical diagram drawing (valid for 4.80 H SST – 4.300 H SST) - 46 -...
  • Page 47 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 47 -...
  • Page 48 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 48 -...
  • Page 49 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 49 -...
  • Page 50 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 50 -...
  • Page 51 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 51 -...
  • Page 52 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 52 -...
  • Page 53 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 53 -...
  • Page 54 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 54 -...
  • Page 55 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 55 -...
  • Page 56 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 56 -...
  • Page 57 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 57 -...
  • Page 58 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 58 -...
  • Page 59 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 59 -...
  • Page 60 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 60 -...
  • Page 61 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 61 -...
  • Page 62 Operating Instruction and Documentation 4.80 H SST- 4.300 H SST - 62 -...
