Press V/v to select the input, then press
check the box.
x MAIN (for "Zone2" and "Zone3"
Lets you link operation of trigger in zone 2 or
zone 3 to the main receiver.
• Even when this receiver is standby mode (press
?/1 on the remote to turned off this receiver), the
receiver in zone 2 or zone 3 remains turned on. To
turn off all receivers, press ?/1 and AV ?/1 on the
RM-AAL012 remote at the same time (SYSTEM
• Only signals from components connected to the
analog input jacks are output through the ZONE 2
OUT/ZONE 3 OUT jacks. No signals are output
from components connected to only the digital
• When SOURCE is selected, the signals input to the
MULTI CHANNEL INPUT jacks are not output
from the ZONE 2 OUT or ZONE 3 OUT jacks
even when the multi-channel input is selected. The
analog audio signals of the current function are
• When "Tuner" is selected; the same type of radio
station (FM/AM) selected in the main zone is set in
zone 2 and zone 3. However, you can select the
input other than "Tuner" in zone 2 and zone 3.
• When the receiver in the main zone is turned off, or
an input source other than "Tuner" is selected, you
can select a radio station from AM or FM in zone
2. When the receiver in the main zone and zone 2
are turned off, you can select a radio station from
AM or FM in zone 3.
When two of the receivers in the main zone, zone 2
or zone 3 are turned off, you can select a broadcast
from FM/AM/XM/SIRIUS in one zone in which
the receiver is turned on.
Lets you select the zone which plays back the
same music as the main zone when you press
the PARTY button to start the party mode.
You can make settings for the audio to suit
Digital Legato Linear (D.L.L.)
When you set this setting to "AUTO," the
receiver plays back the sound recorded using
lossy compression with high quality sound.
Even the CD sound will be linearized so that
the CD sound quality level will be increased.
A/V Sync (Synchronizes audio
and video output)
Lets you delay the output of audio to minimize
the time gap between audio output and visual
x HDMI AUTO
The time gap between audio output and visual
display for the monitor connected via an
HDMI connection will be adjusted
automatically based on the information for the
TV. This feature is available only when the
monitor supports the A/V Sync function.
x 0 ms – 300 ms
You can adjust the delay from 0 ms to 300 ms
in 10 ms steps.
• This function is useful when you use a large LCD
or plasma monitor or a projector.
• This function does not work in the following cases.
– The multi-channel input is selected.
– "2ch Analog Direct" is being used.
