1 Introduction

1.1 Intended use

This unit is intended for industrial use in gas analysis systems. It's an essential component for conditioning the sample gas to
protect the analysis instrument from residual moisture in the sample gas.
Please note the specifications in the data sheet on the specific intended use, existing material combinations, as well as pressure
and temperature limits.

1.2 Types

The device is delivered with different configurations. The part number given on the type plate informs you about the specific
configuration of your device.

1.3 Scope of delivery

– Cooler
– Product documentation
– Connection-/mounting accessories (optional)

1.4 Ordering instructions

The item number is a code for the configuration of your unit. Please use the following model key:
4496 1 1 1 X 0 4 X X X 0 0 X X
1
2
0
1)
Filter tubing, metric or US, respectively
2 Bühler Technologies GmbH
4
1 1 0
1 1 5
1 2 0
1 2 5
1 3 0
1 3 5
0 0
0 0
0 1
1 0
1 1
1 Product characteristic
Gas cooler models (with 1 heat exchanger)
TC MINI 6111: moderate ambient temperature 40 °C
TC MINI 6112: higher ambient temperature 50 °C
Certifications
Standard unit, no special certification
Supply voltage
24 V DC
1)
Heat exchanger
MTS, metric fittings
MTS-I, US fittings
MTG, metric fittings
MTG, US fitting
MTV, metric
MTV-I, US fitting
Sample gas pumps
without sample gas pump
Moisture detector / filter
without filter, without moisture detector
without filter, 1 moisture detector with block
1 filter, without moisture detector
1 filter with built-in moisture detector
Status outputs
1 Analogue output, 4...20 mA
