NO DESCRIPTION
065 Needle Bearing
066 Screw
067 Lock Plate
068 Screw
069 Stop Plate
070 Gear Case
071 Eccentric Shaft
072 Circlip
073 Striking Fork
074 Pin
075 Spring
076 Screw
077 Knob
078 Knob Spring
079 Locating Piece
080 Screw
081 Screw
082 Switch Knob
083 Bearing
084 Rotor
085 Bearing
087 Air Deflector
088 Stator
089 Motor Housing
090 Label
091 Screw
092 Carbon Brush
093 Brush Holder
094 Label
095 Screw
096 Bottom Cover
097 Self-tapping Screw
098 Left Handle
Please quote the reference TMCCON1500RDV001 onwards. e.g. Front Handle
will be TMCCON1500RDV117.
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
NO DESCRIPTION
099 Power Cable
100 Cable Sheath
101 Cable Clamp
102 Self-tapping Screw
103 Capacitor
104 Switch
105 Inductor
106 Anti-vibration Ring
107 Self-tapping Screw
108 Right Handle
109 Speed Control
110 Clamp Collar
111 Thumbscrew
112 Front Handle Clamp
113 Nut
114 Depth Stop Clamp
115 Bolt
116 Straight Pin
117 Front Handle
118 Depth Stop
119 Grease Pot
120 Dust Cap
121 Spanner
122 Anti-vibration Bolt
123 Anti-vibration Washer
124 Anti-vibration Spring
