- Page 1 SDS+ ROTARY HAMMER DRILL MODEL NO: CON400RHD PART NO: 6479510 OPERATION & MAINTENANCE INSTRUCTIONS LS0812...
-
Page 2: What's Supplied
This guarantee does not effect your statutory rights. WHAT’S SUPPLIED Unpack your tool and make sure that the following items are present. Should there be any damage caused during transit contact your Clarke dealer immediately. Rotary Hammer Drill with SDS+ Chuck Auxiliary Handle... -
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL OF THE WARNINGS LISTED BELOW REFERS TO YOUR MAINS OPERATED (CORDED) POWER TOOL OR BATTERY OPERATED (CORDLESS) POWER TOOL. -
Page 4: Personal Safety
PERSONAL SAFETY 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 5: Hammer Drill Safety Instructions
2. Using the correct bit. Use the appropriate drill bit for the material being drilled. Different bits are available from your Clarke dealer. 3. Use of the mains cable. Keep the mains cable well away from the drill and ensure an adequate electrical supply is close at hand so that the operation is not restricted by the length of the cable. -
Page 6: Specific Safety Rules
SPECIFIC SAFETY RULES 10. For your safety, do not plug in your power tool until you have read and understood this Owner's Manual. 11. WEAR EYE PROTECTION. Use face or dust mask along with safety goggles if operation is dusty.Use hearing protection, particularly during extended periods of operation, wear safety shoes. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 8 SETUP WARNING: TO REDUCE THE RISK OF PERSONAL INJURY, TURN THE UNIT OFF AND DISCONNECT IT FROM THE MAINS SUPPLY BEFORE INSTALLING AND REMOVING ACCESSORIES AUXILIARY HANDLE & DEPTH STOP NOTE: The depth stop can only be used if the handle is installed. 1.
- Page 9 5. To remove a bit pull back the locking sleeve and pull the bit out of the tool holder. NOTE: The supplied dust shield cap can be placed over the shaft of the bits before inserting it into the SDS chuck this is used when drilling overhead to prevent dust or debris entering the drill vents.
-
Page 10: Operation
OPERATION PROPER HAND POSITION Always hold the drill securely and use the auxiliary handle as shown. SELECTING THE OPERATING MODE CAUTION: THIS OPERATION SHOULD ONLY BE PERFORMED WHEN THE DRILL IS AT A COMPLETE STOP. 1. Rotate the mode selector to the required position. -
Page 11: Switching On And Off
SWITCHING ON & OFF 1. Insert the plug into a mains power socket. 2. Squeeze the trigger to start the drill. 3. During use, press the trigger lock- on button and the drill will run continuously without you needing to press the trigger. 4. -
Page 12: Before Use
• All bearings etc, in this tool are lubricated with a sufficient amount of high grade lubricant for the tools lifetime under normal operating conditions, therefore no further lubrication is necessary • Refer to your CLARKE dealer if internal maintenance is required. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Specifications
SPECIFICATIONS CON400RHD Operating voltage and frequency 230V ~ 50Hz Input Wattage @ 230V Typical load 400 W Chuck Capacity 1.5 - 10 mm Rotational Speed 0-1500 RPM Impact Rating 0-6600 (blows/min) Maximum drilling diameter Steel: Ø 10 mm Masonry Ø 10 mm Wood Ø... -
Page 14: Replacement Parts
REPLACEMENT PARTS The following parts are replaceable by the end user, refer to the Clarke servicing department for any other repairs. ESCRIPTION UMBER Dust Shield Cup TMCCON400RHD01 Keyed 3 Jaw Chuck TMCCON400RHD02 Auxiliary Handle TMCCON400RHD03 Depth Stop Rod TMCCON400RHD04 1 x 150 mm x 6 mm Drill Bit... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
