- Page 1 ROTARY HAMMER DRILL MODEL NO: CON1200RD PART NO: 6479600 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL1021 - ISS 5...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Hammer Drill. The CON1200RD is designed for general drilling/masonry drilling/chiselling/drill & hammer use in light industrial applications. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL WARNINGS LISTED BELOW REFERS TO YOUR HAMMER DRILL. WORK AREA 1. Keep work area clean and well lit. Cluttered and dark areas invite accidents. - Page 4 5. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. POWER TOOL USE AND CARE 1. Do not force the power tool. Use the correct power tool for your application.
-
Page 5: Safety Symbols
SAFETY SYMBOLS Read instruction Wear dust mask manual before use Class 2 Double Wear ear defenders Insulated CE Mark Wear safety glasses Weee Directive ENVIRONMENTAL RECYCLING POLICY Through purchase of this product, the customer is taking on the obligation to deal with the WEEE in accordance with the WEEE regulations in relation to the treatment, recycling &... -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. Connecting it to any other power source may cause damage. - Page 7 OVERVIEW NO DESCRIPTION NO DESCRIPTION SDS+ Chuck Rear Handle Rotation Stop Switch Hammer Action Selector Grease Port Cover Motor Trigger Front Handle Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 8: Before Use
BEFORE USE INSERTING A DRILL BIT / CHISEL The chuck clamps SDS+ drill bits and chisels without the need for a chuck key. 1. Pull back the collar. 2. Insert the bit 3. Turn the bit in the chuck until it latches. -
Page 9: Selecting The Operating Mode
POSITIONING THE FRONT HANDLE The front handle can be positioned left, right or centre as required. 1. Loosen the handle by twisting it clockwise (when viewed from above). 2. Rotate the handle to the required position. 3. Secure the handle by twisting it anticlockwise (when viewed from above). - Page 10 ROTATION ON/OFF SELECTOR Some jobs require the chuck to remain stationary yet still have the hammer effect, such as chiselling concrete, plaster etc. • Set the rotation selector to the right for “no rotation”. • Set the rotation selector to the left for “normal rotation”.
-
Page 11: Using The Drill
USING THE DRILL BEFORE STARTING WORK 1. Before drilling into walls and floors etc., check first that there are no hidden electrical cables, gas or water pipes etc. 2. Check the mains voltage before plugging in and switching on. 3. Ensure the work area is as hazard free as possible. STARTING WORK 1. -
Page 12: Drilling Tips
DRILL BITS A Wide choice of SDS+ and standard drill bits are readily available for this drill. Please contact your local stockist or visit the Clarke website at: www.clarkeinternational.com Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Maintenance And Servicing
MAINTENANCE AND SERVICING 1. After use, remove the drill bit and tap the side of the chuck to remove any dust or chippings etc. 2. Keep the handle clean and free from oil and grease. 3. Worn or damaged parts must be replaced by qualified personnel. 4. -
Page 14: Specifications
SPECIFICATIONS Operating Voltage and Frequency 230V AC~ 50Hz -1phase Rated Input Power 1200W Chuck capacity/type SDS+ Plus 13mm keyed chuck adapter Rotational Speed Drill Mode 860 rpm Drill/Hammer Mode 820 rpm Impact Rating 4050 (blows/min) Maximum Drilling Capacity: Wood - 42 mm, Steel - 13 mm, Concrete - 32 mm Sound Pressure Level... -
Page 15: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 16: Parts List
PARTS LIST DESCRIPTION DESCRIPTION Rubber Cap Cylinder Case Circlip Circlip Chuck Grip Bearing Spring Gearbox Chuck Barrel Small Gear Screw Washer Washer Bearing Washer Washer Oil Seal Gear 10 Washer Fixing Plate 11 Circlip Washer 12 Bearing Ball 13 Ball Plate 14 Flex Spring... - Page 17 DESCRIPTION DESCRIPTION 61 Hammer Action Selector Screw 62 Screw Spring 63 Retainer Anti-vibration Board 64 Bearing Screw 65 Rotor Anti-vibration Cover 66 Screw Right Side Of Handle 67 Stator Trigger 68 Bearing Capacitor 69 Motor Casing Inductor 70 Screw Power Cable 71 Brush Cable Sheath 72 Brush Holder...
- Page 18 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 19: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
