- Page 1 6 FUNCTION HAMMER DRILL MODEL NO: CON1500RHD PART NO: 6479508 OPERATION & MAINTENANCE INSTRUCTIONS GC0712...
-
Page 2: What's Supplied
This guarantee does not effect your statutory rights. WHAT’S SUPPLIED Unpack your tool and make sure that the following items are present. Should there be any damage caused during transit contact your Clarke dealer immediately. Rotary Hammer Drill Side Handle Assembly (fitted) 1 x Pin Wrench 1 x Metal Key Chuck &... -
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL OF THE WARNINGS LISTED BELOW REFERS TO YOUR MAINS OPERATED (CORDED) POWER TOOL OR BATTERY OPERATED (CORDLESS) POWER TOOL. -
Page 4: Personal Safety
PERSONAL SAFETY 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 5: Hammer Drill Safety Instructions
2. Using the correct bit. Use the appropriate drill bit for the material being drilled. Different bits are available from your Clarke dealer. 3. Use of the mains cable. Keep the mains cable well away from the drill and ensure an adequate electrical supply is close at hand so that the operation is not restricted by the length of the cable. -
Page 6: Specific Safety Rules
SPECIFIC SAFETY RULES 10. For your safety, do not plug in your power tool until you have read and understood this owner's manual. 11. Wear eye protection. Use face or dust mask along with safety goggles if operation is dusty.Use hearing protection, particularly during extended periods of operation, wear safety shoes. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 8: Adjusting The Side Handle
SETUP WARNING: TO REDUCE THE RISK OF PERSONAL INJURY, TURN THE UNIT OFF AND DISCONNECT IT FROM THE MAINS SUPPLY BEFORE INSTALLING AND REMOVING ACCESSORIES ADJUSTING THE SIDE HANDLE 1. Loosen the handle by rotating the shaft of the handle clockwise (when viewed from above) 2. -
Page 9: Inserting And Removing Sds Bits
INSERTING AND REMOVING SDS BITS. This machine uses SDS bits and chisels 1. Wipe the bit shank clean. 2. Pull back the locking sleeve and insert the SDS bit. 3. Release the locking sleeve. 4. Pull on the bit to check that it is properly locked. -
Page 10: Operation
OPERATION PROPER HAND POSITION Always hold the drill securely and use the auxiliary handle as shown. SELECTING THE OPERATING MODE CAUTION: THIS OPERATION SHOULD ONLY BE PERFORMED WHEN THE DRILL IS AT A COMPLETE STOP. 1. Push and hold the red button on the Function/Mode selectors. -
Page 11: Switching On And Off
SWITCHING ON & OFF 1. Insert the mains plug into a mains power socket. • The green LED on the handle of the drill will come on to indicate that power is present. • If the red LED comes on, it is to indicate that the carbon brushes in the drill motor are worn and should be replaced... -
Page 12: Before Use
• There are no other user servicable parts in this machine. Refer to your CLARKE dealer if internal maintenance is required. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Specifications
Dimensions (L x W x H) 390 x 250 x 105 mm Weight 5.95 Kg REPLACEMENT PARTS The following parts are replaceable by the end user, refer to the Clarke servicing department for any other repairs or damage. ESCRIPTION UMBER Dust proof cover... -
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 15 NOTES _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
