Specifications

Projection System
Picture Tube
Projection Lenses
Antenna
Television System
Channel Coverage
DTV
VHF
UHF
CATV
Power Requirements
Number of Inputs/Outputs
Video (IN)
S Video (IN)
Component Video Input
Audio (IN)
Audio (OUT)
Subwoofer (Out)
SELECT OUT
Digital Audio Optical Output
Dolby Digital/PCM
CONTROL S (IN/OUT)
i.LINK S200
Supplied Accessories
Remote Control
AA (R6) Batteries
Optional Accessories
AV Cable
Audio Cable
i.LINK Cable
Component Video Cable
Rear Speakers
Screen Size
3 picture tubes, 3 lenses, horizontal in-line system
7-inch high-brightness monochrome tubes (6.3 raster size),
with optical coupling and liquid cooling system
High performance, large diameter hybrid lens F1.05
75 ohm external terminal for VHF/UHF
NTSC, American TV Standard, ATSC
2-69
2-13
14-69
1-125
120V AC, 60 Hz
4 total (1 on front panel)
4 (1 on front panel)
2 (Y, P
, P
)
B
R
6 total (1 on front panel)
1
1
1 Video
1 Audio
1
1
2
RM-Y185
2 supplied for remote control
VMC-810/820/830 HG
RKC-515HG
VMC-IL4415 (4-pin to 4-pin, 1.5 meters), VMC-IL4435 (4-pin to 4-pin, 3.5 meters)
VMC-10/30 HG
SS-MB115
57 in measured diagonally (KDP-57XBR2)
65 in measured diagonally (KDP-65XBR2)
1 Vp-p, 75 ohms unbalanced, sync negative
Y: 1 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Y: 1.0 Vp-p, 75 ohms unbalanced, sync
negative; P
: 0.7 Vp-p, 75 ohms
B
P
: 0.7 Vp-p, 75 ohms
R
500 mVrms (100% modulation)
Impedance: 47 kilohm
More than 408 mVrms at the maximum volume
setting (Variable)
More than 408 mVrms (Fixed)
Impedance (output): 2 kilohms
More than 408mVrms at the maximum volume
setting
Impedance (output): 2 kilohms
Cutoff frequency: 100Hz
1 Vp-p, 75 ohms unbalanced, sync negative
More than 408 mVrms (100% modulation)
Impedance (output): 2 kilohms
Optical Rectangular (1)
4-pin S200 i.LINK terminal (2)
